Power Line Carrier Communication Channel Model Applied to Shipboard Electric Network

Abstract:

It is necessary to build a particular communication channel model to investigate shipboard electric network power line carrier technology. And this model must live up to characteristics of ordinary power line as well as shipboard electric network. This paper confirms the lighting network as the PLC application network in the first place, on the basis of lumped parameter transmission model, analyzes shipboard cable AC resistance, describes pulse noises of shipboard loads, and builds the shipboard PLC channel model. Comparing with the PLC multipath model of large land electric network, this channel model also reflects characteristics of high frequency time-varying selective fading and low frequency smooth fading, at the same time, lives up to shipboard electric network characteristics.

• Periodical: Applied Mechanics and Materials (Volumes 385-386)
• Pages: 1164-1170
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.385-386.1164
• Online since: August 2013
• Authors: Hong Jiang Li, Hao Lan Zhang
• Keywords: AC Resistance, Lumped Parameter Model, Power Line Carrier, Shipboard Electric Network

References

[1] Dianmo Zhang. Foundation of Power Line Carrier Communication, NanJing: Water Conservancy and Electric Power, 1999, pp.6-10.

[2] Massimo Antoniali, Andrea M. Tonello, Matteo Lenardon, Andrea Qualizza. Measurements and Analysis of PLC Channels in a Cruise Ship, presented at the 2011 Int. Conf. Power Line Communication and Its Application, Ocala.

DOI: 10.1109/isplc.2011.5764372

[3] Haiqing OU. PLC Development Trend Analysis. Beijing : Commmunication World., 2005, pp.34-35.

[4] Lin Li, Bing Shen, Jingwu Zhuang. Shipboard Power System. WuHan: CA: Naval University of Engineering, 2001, pp.199-210.

[5] Wu Qiang, Zhen Hongbin, Zhang Chao. Electrical Equipment Surface Ship. WuHan: Naval University of Engineering Press, 2011, pp.86-92.

[6] Mingyang Yu, Lei Tong. Skin effect on Conductivity of Copper Bus, Electrical Technology, vol. 23, no. 4. p.42, (2007).

[7] Yu Zhang, Wenhui Hao, Jinghui Gao. Microwave Technique and Its Application. XiAn: Electron Science, 2006, p.105.

[8] Xiangyu Zhen, Qinqin Yang, Xiaofang Zhou, Jianlin Chen. Noise Molding and Analysis of In-door Low Voltage Power Line Channel. Nanjing: Circuit and System Transaction, Vol. 4, 2011, p.59.

[9] S. Barmada, L. Bellanti, M. Raugi, and M, Tucci, Analysis of Power-line Communication Channels in Ships, in IEEE trans. Vehicular Technology, Vol. 59 , n. 7, Sept. 201, pp.3161-3170.

DOI: 10.1109/tvt.2010.2052474

[10] Chang Sun, Yun Han. Design of Warship Control System Environment Protection and EMC, Shipboard Electricity, vol. 12, no. 40. p.53, (2010).

[11] Feng Lv, Guoyuan Lv. Model of Low Voltage Power Line Communication Channel, Power System Communication, vol. 1, no. 9. pp.30-32, (2004).

[12] H. Guan Meng, Chen Yu. Modeling and Analysis of Noise Effects on Broadband Power-line Communication, Power Delivery, IEEE Trans. Electron Devices, vol. ED-11, p.54–59, Jan. (2005).

DOI: 10.1109/tpwrd.2005.844349

[13] Zimmermann M. Model for the power line channel,. in IEEE Trans. Communicaion., Vol. 50, n. 4, October 2002, pp.553-559.

[14] Y Hirayama, H Okada, T Yamazato, et al. Noise Analysis on Wide-band PLC with High Sampling Rate and Long Observation Time, presented at the 2011 Int. Conf. Power Line Communication and Its Application, Ocala.

[15] A. M. Tonello, and F. Versolatto, Bottom-Up Statistical PLC Channel Modeling-PartⅡ: Inferring the Statistics, in IEEE Trans. Power DEL., Vol. 25, n. 4, October 2010, pp.2356-2363.

DOI: 10.1109/tpwrd.2010.2053561
