Analysis of the Ground Rib Axial Profile of the Spiral Guid Roller

Abstract:

Based on the geometric and kinematic relationship between the spiral guide rollers rib and the grinding wheel in the rib grinding with the special machine, the ribs shape surface after grinding was analysised, and the equations for the ground rib axial profile were established. Numerical analysis was conducted in an example, and the results show that the ground rib axial profile is approximately linear in most region, but seriously nonlinear in the root region of about 0.5mm height, and the profile inclination direction changes when the vertical angle of grinding wheel head is less than a value which is slightly less than the helix angle of the guide roller.

• Periodical: Applied Mechanics and Materials (Volumes 385-386)
• Pages: 216-219
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.385-386.216
• Online since: August 2013
• Authors: Zuo Bin Gao, Wei Ma, Xiao Zhong Deng
• Keywords: Axial Profile, Grinding, Rib, Spiral Guide Roller

References

[1] XIA Xintao, MA Wei, XIE Tancheng. Rolling bearing manufacturing technology[M]. Beijing: China Machine Press, (2007).

[2] CHINESE MECHANICAL ENGINEERING SOCIETY. Chinese mechanical engineering technology Roadmap [M]. Beijing: China Science and Technology Press, 2011. 8: pp.209-214.

[3] XIA Xintao, ZHENG Yuanzhong. Theoretical profile and its simplifying of spiral guide roller[J]. Bearing. 1986, No. 4: 15-19.

[4] LIU Zhaohong, WANG Shijun, WANG Youwei. Design of the superfinishing guider for tapered rollers[J]. Bearing. 2004, No. 6: 15-16.

[5] LI Guixian. Spatial Geometry Modeling and Its Application in Engineering[M]. High Education Press, Beijing, China. (2007).

[6] LI Yangcheng. space analytic geometry[M]. Science Press, Beijing, China. (2007).
