Port-Controlled Hamiltonian Control of IM Based on Back-to-Back Converter

Abstract:

A method of port-controlled Hamiltonian (PCH) systems energy-shaping control is presented for the four-quadrant control problem of squirrel cage induction motor (IM) drive system. First, the PCH models of IM drive system are developed. Then, the PCH controllers are designed based on the control theory of closed-loop state error PCH system. The coordinated control of the grid-side and the motor-side are applied in Matlab/simulink, which the motor-side is started after the grid-side is achieved up to stable. The controlled system can be achieved that DC bus voltage controllable, unity power factor, energy bidirectional flow, IM run in the four-quadrant, etc.

• Periodical: Applied Mechanics and Materials (Volumes 385-386)
• Pages: 839-842
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.385-386.839
• Online since: August 2013
• Authors: Ning Zhu, Hai Sheng Yu, Bing Qiang Shan
• Keywords: Coordinated Control, Four-Quadrant, Hamiltonian System, Induction Motor (IM)

References

[1] Y. Ruan and W. Chen: Motion Control System (Tsinghua University Press, Beijing 2009).

[2] R. Ortega, A J. Van Der Schaft, B. Maschkec, et al. Interconnection and damping assignment passivity-based control of port-controlled Hamiltonian systems. Automatica, Vol. 38, no. 4, p.585–596, (2002).

DOI: 10.1016/s0005-1098(01)00278-3

[3] H. Yu, J. Yu, and X. Liu. Passivity-based control of PMSM based on state error PCH method and PI regulation. ICIC Express Letters, Vol. 5, no. 8, pp.2811-2816, (2011).

[4] Q. Song, H. Yu and N. Zhu． Port-controlled Hamiltonian control of PMSM based on back to back four-quadrant converter. Journal of Qingdao University(Engineering & Technology Edition), 2011, 26(2): 1-7.

[5] J. Liu, H. Yu and X. Wei. Port-controlled Hamiltonian control of asynchronous motors and L2-gain disturbance attenuation. Electric Machines& Control Application. 2010, 37(10): 10-16.
