Design and Performance Analysis of Digital Pressure Relief Valve of Water-Based Hydraulic

Abstract:

this paper use the stepper motor as driver, designed the structure of a digital pressure relief valve of water-based hydraulic, and establishment mathematical model of the valve element cavitation flow field, simulated and analyzed the different the valve element cavity volume and rounded of water pressure relief valves cavitation flow field by use Fluent software. The results showed that: It can suppressed cavitation that appropriate increases cavity volume and reduced the spool fillet.

• Periodical: Applied Mechanics and Materials (Volume 387)
• Pages: 369-373
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.387.369
• Online since: August 2013
• Authors: Tian Chi Jia, Zhang Yong Wu, Juan Wang, Ru Guang Feng, Yan Jin Qin
• Keywords: Digital Pressure Relief Valve, Fluent Software, Performance Analysis, Water-Based Hydraulic Medium

References

[1] Yiqun Wang, Jin Lang. Water Hydraulic Power and Its Prospects[D]. Hebei, Yanshan University, (2003).

[2] Songjin Li, Jian Ruan, Yongju Gong n. Introduction Advanced Hydraulic Drive Technology[M]. Harbin: Press of Harbin Institute of Technology, (2008).

[3] Jian]Ke, Sining Liu, Mingheng Xu. The Latest Research of The Water Hydraulic Power Drive Technology[J]. Machine Tool & Hydraulics. 2001, (2): 12-14.

[4] Shujuan Zheng. CFD Calculations of The Internal Flow Field of The Valve Element Movement of The Poppet Valve[D]. Taiyuan, Taiyuan University of Science & Technology, (2005).

[5] Zhanzhong Han, Jing Wang, Xiaoping Lan. Examples and Applications of Fluid Engineering simulation[M]. Beijin, Press of Beijin University of Science & Technology, (2007).

[6] Engang Zhao. Research of the Digital Pressure Relief Valve of Pure Water . Kunming, Kunming University of Science & Technology, (2008).
