Effect of Temperature Change on Capacitance of RF MEMS Clamped-Clamped Capacitive Switch

Abstract:

The effects of temperature change on the pull-in behavior and on the capacitance of the RF MEMS clamped-clamped capacitive switch are quite heavy because of the larger slenderness ratio of the MEMS clamped-clamped switch beam. A one-dimensional three-stage static model with temperature change for analyzing the beam was presented based on the small displacement assumptions, in which the clamped-clamped beam was subjected to both the electrostatic forces and the temperature change. First, the model was used to calculate the capacitance of the RF MEMS clamped-clamped capacitive switch in different states. Then , the effects of temperature change on the capacitance of the clamped-clamped capacitive switch for some different geometry dimensions were analyzed. From the analysis the effect of some geometry dimensions, such as the length of the beam, the depth of the beam and so on, at different temperature changes on the capacitance can be understood and some conclusions may be useful to the design of the MEMS clamped-clamped capacitive switch with the temperature change.

• Periodical: Applied Mechanics and Materials (Volume 389)
• Pages: 533-541
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.389.533
• Online since: August 2013
• Authors: Tian Jie Cao
• Keywords: Capacitance Switch, MEMS, Pull-In Voltage, Temperature Change
