Application of Integrated Design of the Belt Drive System Based on the Platform of Research and Development of the VBA

Abstract:

In order to the integrated design of the geometric parameters and drawing the pulley parts, based on R & D platform of the VBA with the CAD software, hence after analyzing the selection belt type, determine the reference diameter of the belt pulley, choosing length and the amount of the belt, and designing and drawing the pulley parts, in which include the drawing the tooth of v belt pulley, chamfers and grooves, keyway, hatches, and part dimension, etc. Conventional belt drive system is successfully developed. The design results show that the program is running smoothly, the result is correct with the friendly interface, it can provide a convenient tool to rapidly design of project for the belt drive system.

• Periodical: Applied Mechanics and Materials (Volume 389)
• Pages: 953-956
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.389.953
• Online since: August 2013
• Authors: Xian Zhang Feng, Yan Mei Cui, Li Hong Yu, Zhi Qiang Jiang, Jun Wei Cheng, Liang Ji Chen
• Keywords: Belt Drive System, Belt Pulley, CAD, Integrated Design, VBA

References

[1] C. Bryant, R. Concept Generation from the Functional Basis of Design, Proceedings of International Conference on Engineering Design ICED 05, Melbourne, 15-18 Au-gust (2005).

[2] T. Kurtoglu. Automated Synthesis of Electromechanical Design Configurations from Empirical Analysis of Function to Form Mapping, Journal of Engineering Design, 2009, 20(1): 83-104.

DOI: 10.1080/09544820701546165

[3] YANG Hui, LI Bin, HU Yinghao. Design of CPU Radiator Mould. Aluminum Fabrication, 2009, 191(6): 40-45.

[4] SHI L Q, ZHANG SH G, SUN T, et al. Test and analysis on Nan hardness using an AFM-based system. Opt. Precision Eng., 2007, 15(5): 725-729.

[5] Wu Xiaolin. The status of dry cooling technology of thermal power plants in China. International Electric Power for China, 2005, 9(1): 15-18.
