Study of Nonlinear Phenomena and Chaos Control in Single-Phase SPWM H Bridge Inverter

Abstract:

This paper introduces the work principle of single-phase SPWM H bridge inverter and builds up the mathematics model according to KVL and KCL. It can easy to observe nonlinear phenomena in the circuit after simulation the model. According to the characteristics of single-phase SPWM H bridge inverter, both resonant parametric perturbation and TDFC are good ways to eliminate chaotic behavior of inverter and made the system changing from chaos to stable period. It has a very important practical value and theoretical significance for stability design of single-phase SPWM H bridge inverter.

• Periodical: Applied Mechanics and Materials (Volume 39)
• Pages: 1-6
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.39.1
• Online since: November 2010
• Authors: Wei Jiang, Fang Yuan, Wen Long Hu
• Keywords: Chaos Control, H Bridge Inverter, Nonlinear, SPWM

References

[1] J. Baillieul, R.W. Brockett and R.B. Washburn: Chaotic Motion in Nonlinear Feedback Systems. IEEE Transactions on Circuits and Systems, Vol. 27, No. 11, (1980), pp.990-997.

DOI: 10.1109/tcs.1980.1084739

[2] J.H.B. Deane and D.C. Hamill: Chaotic Behavior in a Current-mode Controlled DC–DC Converter. Electronics Letters, Vol. 27, No. 3, (1991), pp.1172-1173.

DOI: 10.1049/el:19910731

[3] J. Deane, D.D. Hamill: Instability, Subharmonics, and Chaos in Power Electronics Circuits. IEEE Transactions on Power Electronics, Vol. 5, No. 3, (1990), pp.260-268.

DOI: 10.1109/63.56516

[4] C.K. Tse: Complex Behavior of Switching Power Converters (CRC Press, Boca Roton 2003).

[5] B. Robert and C. Robert: Border Collision Bifurcations in a One-dimensional Piecewise Smooth Map for a PWM Current-programmed H-bridge Inverter. International Journal of Control, Vol. 27, No. 75, (2002), pp.1356-1367.

DOI: 10.1080/0020717021000023771

[6] X.M. Wang and B. Zhang: Mechanism of Border-collision Bifurcations and Chaos in H-bridge Direct Current Chopper. Proceeding of the CSEE, Vol. 29, No. 9, (2009), pp.22-26.

[7] X.M. Wang and B. Zhang: Study of Bifurcation and Chaos in Single–phase SPWM Inverter". Transactions of China Electrotechnical Society, Vol. 24, No. 1, (2009), pp.101-107.

[8] H.H.C. Iu and B. Robert: Control of Chaos in a PWM Current-mode H-bridge Inverter Using Time-delayed Feedback. IEEE Transactions on Circuits Systems, Vol. 50, No. 8, (2003), pp.1125-1129.

DOI: 10.1109/tcsi.2003.815220

[9] Y.F. Zhou, C.K. Tse, S.S. Qiu and F.C.M. Lau: Applying Resonant Parametric Perturbarion to Control Chaos in the Buck DC/DC Converter with Phase Shift and Frequency Mismatch Considerations. International Journal of Bifurcation and Chaos, Vol. 13, No. 11, (2003).

DOI: 10.1142/s0218127403008685

[10] W.G. Lu, L.W. Zhou: Time-delayed Feedback Control of Chaos in Boost Converter and its Optimization. Acta Physica Sinica, Vol. 56, No. 11, (2007), pp.6275-6281.
