The Study of Cavity Flow and Transpiration Cooling in Supersonic Combustion

Abstract:

To unravel the flow and heat transfer mechanism of the cavity in supersonic combustion, this paper studied the interaction of cavities and shear-layers by experiments and numerical simulation. The experiments of Nero-particle Plane Laser Scatter (NPLS) and Plane Laser-Induced Fluorescence (PLIF) were conducted to study the cavity shear-layer. In the same supersonic condition the flow was studied by the method of Large Eddy Simulation (LES). And we discussed the cavity shear-layer influence to supersonic flow and combustion, analyzed the evolvement of injection shear-layer, probed into the heat transfer of supersonic combustion, and studied the transpiration cooling of cavities. The results show: in supersonic combustion, the initial flame spreads to the upstream through the cavity shear layer, the highest wall temperature occur at the rear edge of cavity, and transpiration cooling can effectively protect the wall materials.

• Periodical: Applied Mechanics and Materials (Volume 390)
• Pages: 370-374
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.390.370
• Online since: August 2013
• Authors: Hai Yyan Wu, Meng Ding, Yi Su
• Keywords: Cavity, Shear Layer, Supersonic Combustion, Transpiration Cooling

References

[1] Ferlemann. S.M., Mcclinton C.R., Hyper-X Mach 7 scramjet design, ground test and flight results. AIAA Paper: 2005-3322. (2005).

DOI: 10.2514/6.2005-3322

[2] Fangpei, Liang E R., A stability study of the developing mixing layer formed by two supersonic laminar streams. AIAA Paper: 93-0245. (1993).

DOI: 10.2514/6.1993-345

[3] Hank J.M., Richard S.M., The X-51A scramjet engine flight demonstration program. AIAA Paper 2008-2540, (2008).

DOI: 10.2514/6.2008-2540

[4] Mcguire J., Boyce R., Mudford N., Comparison of computational and experimental studies on shock induced ignition in scramjets. AIAA Paper: 2005-3394. (2005).

DOI: 10.2514/6.2005-3394

[5] Jacobsen L.S., Carter C.D., Dwenge A. C, Cavity-based injector mixing experiments for supersonic combustors with implications on igniter placement. AIAA Paper : 2006-5268. (2006).

DOI: 10.2514/6.2006-5268

[6] Mathur T., Gruber M., Jackson K., Cavity flame holders for ignition and flame stabilization in scramjets. Propels Power: 17(4) 869-878. (2001).

DOI: 10.2514/2.5818

[7] Zhao Y.X., Yi S.H., Tian L.F., Supersonic flow imaging via nanoparticles. Science in China Series E: Technological Sciences: 52(12): 3640-3648. (2009).

DOI: 10.1007/s11431-009-0281-3

[8] Li M.L., Zhou J., Geng H., Investigations on function of cavity in supersonic combustion using OH PLIF. AIAA Paper: 2004-3657. (2004).

DOI: 10.2514/6.2004-3657

[9] Georgiadis N.J., Alexander J.I., Reshotko E., Development of a hybrid RANS/LES method for compressible mixing layer simulation. AIAA Paper: 2001-0289, (2001).

DOI: 10.2514/6.2001-289
