Time Efficient Testing of Hybrid Electric Vehicles Using Automated Identificated Physical Model Structures

Abstract:

Validation and optimization of technical systems are central activities in the product development process. One part of it is the calibration and validation on a level, which covers the whole vehicle. The aspect, that plays the most important role in both validation and optimization, is the driving condition. Especially in the case of hybrid vehicles, state variables like the state of charge (SOC) have great influence on the operating strategy and therefore on assessment criteria.The article’s objective is to present a procedure, which performs the conditioning and brings the planned maneuver into an order, which reduces the total needed conditioning duration. Thereby a lot of time can be saved, according to the type and amount of the possible maneuver and state values. In addition to optimizing the order of conventional maneuver, the procedure can be used to optimize the list of maneuver in a DOE-Plan. Thereby the maneuver of the individual criteria can be re-sorted as well as the designparametervariation. The IPEK-X-in-the-Loop framework (XiL) is the basis for the approach and will be used as a validation environment in an acoustic roller test bench with vehicle-in-the-loop technology.

• Periodical: Applied Mechanics and Materials (Volume 391)
• Pages: 118-122
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.391.118
• Online since: September 2013
• Authors: Albert Albers, Alexander Schwarz, Rolf Hettel, Matthias Behrendt
• Keywords: Design of Experiment (DOE), Hybrid Testing, Model Identification, Model-Based, Test-Based Optimization, Time-Efficient, X-in-the-Loop

References

[1] Albers, A., Düser, T. (2009). Integration von Simulation und Test am Beispiel Vehicle-in-the-loop auf dem Rollenprüfstand und im Fahrversuch.

[2] Albers, A., Behrendt, & Ott, S. (2010). Validation-Central Activity to Ensure Individual Mobility.

[3] Albers, A., Lerspalungsanti, S., Düser, T., & Ott, S. (2009). Design Parameter Investigation in Customer-oriented Drive Train Development Using Human Senation Modeling Tools.

DOI: 10.1115/detc2009-86363

[4] Albers, A., Alexander Schwarz, Matthias Behrendt, & Rolf Hettel. (2012). Time-efficient method fortest-based optimization of technical systems using physical models. In ASME 2012 International Mechanical Engineering Congress & Exposition. SAE.

DOI: 10.1115/imece2012-89447

[5] Albers A., Schwarz A., Hettel R., Behrendt M. 2012 Method for the time-saving capturing of characteristic Gear shifting Diagrams of vehicles on the Rollertest Bench carried out with dual clutch transmissions 6th International CTI Symposium and Exhibition North America.
