Experiment Study on Force of Hoisting Triangular Gate of Ship Lock in Tidal Reach

Abstract:

A physical model of Jiaogang Ship Lock is established in the paper. Through model test, the force of triangular gate under the condition of opening is studied. The result shows when the upper water level is high water control and when absolute value of upper-lower tidal range is less than 0.5m during the spring tide flux and reflux in the flood season of the Yangtze River in the flood year, the ship lock gate can be opened. When the upper water level is medium water control, the absolute value of upper-lower tidal range to open the ship lock gate should be less than 0.4m. And when the upper water level is low water control, the critical tidal range value is also less than 0.5m.

You might also be interested in these eBooks

Technologies of Mechanical Engineering Industry

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 391)

Pages:

402-405

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.391.402

Citation:

Cite this paper

Online since:

September 2013

Authors:

Teng Wu, Jian Ding, Ling Li Wu

Keywords:

Force Analysis, Physical Model, Ship Lock, Tidal Reach
