Research of Simulation in the Main Circuit of Static Var Generator Based on Cascade H-Bride

Abstract:

This paper introduces the working principle of the research of simulation in the main circuit of Static Var Generator based on Cascade H-Bride and takes the three-phase Static Var Generator based on cascade H-Bride with rated capacity 10kVar,rated voltage 380V for example to proceed the MATLAB simulation. The research shows that the more amount of cascade H-Bride, the more number of output voltage levels in the main circuit of Static Var Generator, the smaller value of voltage waveform distortion factor, and the less harmonic content be inject in electric network, which improves power index.

• Periodical: Applied Mechanics and Materials (Volume 392)
• Pages: 409-412
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.392.409
• Online since: September 2013
• Authors: Xian Bin Dai, Xiao Hua Yuan, Wei Du
• Keywords: Cascade H-Bride, MATLAB Simulation, Static Var Generator (SVG)
