A Hardware-in-the-Loop Platform for a Typical Construction Machinery Real-Time Test

Abstract:

In order to supply a reliable and low-cost method for construction machinery real-time test, take a hydraulic excavator for example. Especially for testing controllers and evaluating the performance of strategies, a hardware-in-the loop platform has been developed based on the xPC real-time system. The hardware-in-the-loop system, including dynamic model of the excavator and an 3D real-time display subsystem, is presented in this paper. The simulation results are also described at the end of the paper.

• Periodical: Applied Mechanics and Materials (Volume 392)
• Pages: 535-538
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.392.535
• Online since: September 2013
• Authors: Wen Gong, Zhong Jian Yu
• Keywords: Construction Machinery, Hardware-in-the-Loop Simulation, Real-Time
