Prefabricated Hole Mathematical Model of Flange-Forming of Tee Pipe with Square Branch

Abstract:

Based on the principle that in the deformation zone the length of bore plain wire does not change, a mathematical model of the prefabricated hole for flange-forming of square hole tee pipe is established, for the difficult problem of the flange-forming prefabricated hole size design for square hole tee pipe. To solve the mathematical model, a numerical method and a software system for the mathematical model is established. In order to verify the reliability of the mathematical model and its solution, the method of finite element simulation is applied to verify the mathematical model and the solving system. The results show that the mathematical model constructed in this paper can relatively accurately make calculation of prefabricated hole size for flange-forming of square hole tee pipe.

• Periodical: Applied Mechanics and Materials (Volumes 395-396)
• Pages: 1154-1157
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.395-396.1154
• Online since: September 2013
• Authors: Zhong Lei Wang, Zhao Dong Li, Gang Cheng, Xin Kai Zhang
• Keywords: Finite Element Method (FEM), Flange-Forming, Prefabricated Hole, Square Hole Tee Pipe

References

[1] M. J Ni: Electric Welder Vol. 31(11) (2001), p.37.

[2] H Hui: Chemical Equipment and Pipeline Vol. (6)(2004), p.60.

[3] S. Y Luo: Petrochemical Eequipment Vol. 22(1)(1993), p, 43.

[4] F. L Gao: Heat Processing Vol. (6)(2003), p, 19.

[5] Z. D Li,J. Z Yu,Z. L Wang, J Cheng. Heat Processing Vol. (23)(2011), p, 19.
