Unified Multi-Error Model for Four Types CNC Machining Center

Abstract:

The error modeling compensation method for improvement the machine tools accuracy has been extensively used in the past decades. To unify the multi-error model for four types CNC machining center, the comprehensive multi-error model of TXYZ type machining center was established based on the homogenous coordinate transformation. According to the analysis of the transmission chain, a unified multi-error model for four types machining center was established based on the Singular Function. Using the unified multi-error model, the mathematical model of four types machining center can be standardized. It is very important for unceasing development of error compensation technology.

• Periodical: Applied Mechanics and Materials (Volumes 395-396)
• Pages: 1162-1169
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.395-396.1162
• Online since: September 2013
• Authors: Kai Guo Fan*, Jian Guo Yang, Li Yan Yang
• Keywords: CNC Machining Center, Multi-Error, Singular Function, Unified Model

References

[1] J. Ni: Journal of Manufacturing Science and Engineering, 119 (1997) 717-725.

[2] J. Ni: China Mechanical Engineering, 8 (1997) 29-33.

[3] Tong HC, Yang JG, Liu GL, et al.: Journal of shanghai jiaotong university 39 (2005) 1400-1403.

[4] R. Chana, P. Manukid: I.J. Machine Tools & Manufacture 44 (2004) 1283-1291.

[5] Shen JH, Li YX, Lu ZZ, Chen ZJ, Yang JG: Journal of Sichuan university 40 (2008) 163-166.

[6] Wang XS, Yang JG, Yan JY: Journal of shanghai jiaotong university 42 (2008) 761-764, 769.

[7] Fan Kaiguo, Yang Jianguo, Yang Liyan: Submitted to Mech. Syst. Signal Pr. (2013).
