Study of Topology and Control Strategy of the Bidirectional Energy Storage Converter Based on Three-Level

Abstract:

To adapt to the requirements of the charging and discharging of the lithium battery, the paper presents a three-level based bidirectional energy storage converter topology.It has strong adaptability and can manage the charge and discharge of multi-series and parallel battery module. The mathematical model of the converter is analyzed, and the two operation modes of the converter control strategy are studied; Analysis the feed-forward decoupling control of three-level rectifier, and the variable scale factor is used to control midpoint potential. The simulation results demonstrate the feasibility of the design.

• Periodical: Applied Mechanics and Materials (Volumes 397-400)
• Pages: 1169-1173
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.397-400.1169
• Online since: September 2013
• Authors: Hong Wei Tang, Xi Kun Chen*, Yan Xia Gao
• Keywords: Bidirectional Energy Storage Converter, Feed-Forward Decoupling Control, Three-Level

References

[1] Wenliang Zhang, Ming Qiu and Xiaokang Lai, in: Grid Technology, 2008, 32(7): 1-9. In Chinese.

[2] Gang Liu, Yan Liang, Siquan Hu, et al, in Power Electronics, 2010, 44(10): 12-13. In Chinese.

[3] Lan Wei, Yan Yue and Qizhong Liu, et al, in Power Electronics, 2009, 43(9): 69-71. In Chinese.

[4] Ying Pan and Chenggang Du, in Power Supply System, 2012, 29(2): 6-9. In Chinese.
