Drive Control of a Class of Scan Systems

Abstract:

In order to meet the requirements of the degree of speed stability for scanning motion, a three-phase AC permanent magnet synchronous motor (PMSM) driven by sinusoidal wave was utilized as the actuator to design a drive control system for a class of scan systems. The main performance index，the degree of speed stability was introduced in brief. With the method of parameter matching, the design of rotating speed and torque, the system was realized. The structure and system components were designed. The simulation results show that the designed control system can achieve desired degree of stability and satisfy the performance specifications effectively and rapidly.

• Periodical: Applied Mechanics and Materials (Volumes 397-400)
• Pages: 1184-1187
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.397-400.1184
• Online since: September 2013
• Authors: Cai Xia Wang, Ming Hua Liu, Ning Cai
• Keywords: Degree of Speed Stability, Drive Control, Scan Systems

References

[1] Boshi Chen and Minxun Chen Minxun, in: Speed Regulation of AC Motor, edited by China Machine Press, Beijing, 2005, In Chinese.

[2] Zhaoan Wang and Jinjun Liu, in: Power Electronic Technology, edited by China Machine Press, Beijing, 2009, In Chinese.

[3] Xingzhong Deng, in: Electromechanical control techniques, Huazhong University of Science and Technology Press, Wuhan, 2007, In Chinese.

[4] Antonio Visioli, in: Practical PID control. Springer-Verlag London Limited, (2006).
