Design and Research of Switched Reluctance Motor Converter Used in Electric Vehicle

Abstract:

In recent years, there has been a growing interest in switched reluctance motor when it is widely used in the field of electric vehicles for its simple structure, low cost, high reliability, wide speed range, high response speed, high operating efficiency and strong renewable braking ability. The performance and structure of the power converter will directly affect the efficiency, cost and reliability of SRM, so the reasonable design of SRM power converter is the key to increase the cost performance of the whole SRM speed control system. Based on the principle and advantages of SRM, an improved asymmetrical half-bridge structure power converter with soft-switching is proposed for SRD in the paper. The DC / DC switching mode power supply for switched reluctance motor drive system is also successfully designed based on LT1247 integrated chip. Experiment results show that the new type of power converter and the DC / DC switching mode power supply can work better on electric vehicles.

• Periodical: Applied Mechanics and Materials (Volumes 40-41)
• Pages: 277-282
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.40-41.277
• Online since: November 2010
• Authors: Jing Sun, Xin Wang
• Keywords: Electric Vehicle (EV), Power Converter, Switch Mode Power Supply (SMPS), Switched Reluctance Motor (SRM)

References

[1] Kang Yunlong. New Energy Vehicles and Power Electronics. Machinery Industry Press(2010).

[2] Meng Runquan, Wang Zhenmin, Xu Chunyu. Principle Analysis and Simulation of a Novel Soft-switching Converter for Switched Reluctance Motor Drive. Journal of China Coal Society, November (2009).

[3] Chen Baoguo. Design of High Frequency Transformer in Switching Power Supply. Hebei Journal of Industrial Science & Technology, February (1999).

[4] Xiong Junfeng, Zheng Shousen and Qi Xinmei. Design and Research of SRM Drive Power Supply for Electric Vehicles, (2009).

[5] Zhong Lianfang. An Investigation on Switched Reluctance Motor and its Power Conveyor Circuits. Journal of South China University of Technology(Natural Science), vol. 24 (1996).

[6] R Krishmam. Switched Reluctance Motor Drives Modeling, Simulation，Analysis，Design，and Applications. USA CRC Press(2001).

[7] Tae-Won Lee, Yong-Ho Yoon, Yuen-Chung Kim, Byoung-Kuk Lee, Chung-Yuen Won. Control of C-dump Converters Fed Switched Reluctance Motor on an Automotive Application. Electric Power Systems Research, Issue 7, May (2007).

DOI: 10.1109/pesc.2004.1355614
