Construction and Simulation of Fuzzy-PID Controller on Stepping Motor

Abstract:

In order to improve the performance of stepping motor system, the modern theory of fuzzy control and classical PID control theory are organically combined, the structure of fuzzy PID controller has built,which is suitable for the stepper motor control requirements, and corresponding control rules have designed that have realized the control of stepping motor. MATLAB software is applied for simulation. Comparing the fuzzy self-tuning PID controller with the conventional PID controller, the simulation results that fuzzy parameter self-tuning PID control system has less overshoot response, shorter reaction time. Fuzzy parameter self-tuning PID control has comprehensively improved the dynamic response performance of stepping motor control system, ensured the control accuracy.

• Periodical: Applied Mechanics and Materials (Volumes 401-403)
• Pages: 1670-1673
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.401-403.1670
• Online since: September 2013
• Authors: Qing Hui Gong, An Min Zhang
• Keywords: Fuzzy PID, Simulation, Stepping Motor

References

[1] Xiaoming Wang. Single-chip microcomputer control of motor[M]. Beijing: Beijing University of Aeronautics and Astronautics Press, (2002).

[2] Tingqi Wang. Research of the brushless DC motor control system based on DSP [D]. Harbin: Harbin Institute of Technology Master Thesis, (2007).

[3] Cheok A D. Use of Fuzzy Logic for Modeling, Estimation, and Prediction in Switehed Reluctance Motor Drives[J]. IEEE Trans. on Industrial Electronies. 1999, 46(6): 1207一1224.

DOI: 10.1109/41.808012

[4] Ertugrul, N, Cheok A D. Indirect Angle Estation in Switched Reluctance Motor Drive Using Fuzzy Logic Based Motor Model[A]. Proe. of IEEE Trans. on Power Electron[C]. 1998: 845-851.

DOI: 10.1109/63.892817

[5] Vadell J E, Chiang L E, Stepping Motor Driving by Controlled-Energy Discharge[J]. IEEE Trans. on Industrial Electronics. 2000, 46(1): 52-60.

DOI: 10.1109/41.744388
