Parallel Manipulators' Analysis by Transmission Angle

Abstract:

This paper presents a novel common approach to analysis the transmission angle of a type of parallel manipulators whose traveling plate has only translation in the workspace and each limb is made up of three joints and two moving links. Two types of transmission angles are defined to evaluate the kinematic performance of parallel manipulators, with which the direct and indirect singularities can be identified in a straightforward manner. Considering the effects of transmission angles, a global and comprehensive index is presented. The kinematic optimization of a new manipulator has been taken as an example to illustrate the effectiveness of this approach.

• Periodical: Applied Mechanics and Materials (Volumes 401-403)
• Pages: 226-230
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.401-403.226
• Online since: September 2013
• Authors: Jiang Ping Mei, Li Hong Hu
• Keywords: Optimal Design, Parallel Manipulator, Singular Configuration, Transmission Angle

References

[1] Clavel. R., 1990, 'Device for the Movement and Positioning of an Element in Space, ', United States Patent No. 4, 976, 582.

[2] HUANG T, LI Z X, LI M. Conceptual design and dimensional synthesis of a novel 2-DOF translational parallel robot for pick-and-place operations[J]. ASME Journal of Mechanical Design, 2004, 126(5), 449-455.

DOI: 10.1115/1.1711822

[3] Hervé J. M. , Sparacino F., Star, a New Concept in Robotics, 3rd International Workshop on Advances in Robot Kinematics, September 7-9, 1992, Ferrara~ Italy, pp.176-183.

[4] Tsai, L. W. and Stamper, R. E., 1996, 'A Parallel Manipulator with Only Translational Degrees of Freedom, ', MECH-1152, Proc. of the 1996 ASME Design Engineering Technical Conferences, Irvine, CA.

DOI: 10.1115/96-detc/mech-1152

[5] Wenger, P., and Chablat, D., 2000, 'Kinematic Analysis of a New Parallel Machine Tool: the Orthoglide, ', Advances in Robot Kinematics, J. Lenarcˇicˇ and M. M. Stanisˇic´, eds., Kluwer Academic Publishers, p.305–314.

DOI: 10.1007/978-94-011-4120-8_32

[6] Huang Tian, Li Meng, Li Zhanxian, Chetwynd, Derek G., Whitehouse, David J. Optimal kinematic design of 2-DOF parallel manipulators with well-shaped workspace bounded by a specified conditioning index. IEEE Transactions on Robotics and Automation, v 20, n 3, pp.538-543, June (2004).

DOI: 10.1109/tra.2004.824690

[7] Von H. Alt, Der ubertragungswinkel und seine bedeutung fur dar konstruieren periodischer gerriebe, Werksstattstechnik 26(Heft4)(1932), 61-65.

[8] LiMin Zhang, JiangPing Mei, XueMan Zhao and Tian Huang, Demensional synthesis of the Delta robot using transmission angle constraints, Chinese Journal of Mechanical Engineering. 2010, 03: 1-7.

[9] Jiangping Mei, Liangan Zhang, A three translational degrees of freedom robot mechanism, China. 201010505933. 8[P]. 2011. 02. 02.

[10] J. -P. Merlet, Redundant parallel manipulators, Laboratory Robotics and Automation 8 (1) (1996) 17–24.

DOI: 10.1002/(sici)1098-2728(1996)8:1<17::aid-lra3>3.0.co;2-#

[11] Gosselin CM, Angeles J. A global performance index for the kinematic optimization of robotic manipulators. ASME J Mech Des 1991; 113(3): 220–226.

DOI: 10.1115/1.2912772

[12] Huang, T., Wang, J. S., Gosselin, C. M., and Whitehouse, D. J., 2000, 'Kinematic Synthesis of Hexapods With Prescribed Orientation Capability and Well-Conditioned Dexterity, ', SME J. of Manufacturing Processes, 2. 1., p.36–47.

DOI: 10.1016/s1526-6125(00)70011-9
