Analysis on Heat-Insulating Property of the New-Type Water Transporting Vehicle Based on ANSYS

Abstract:

A new-type heat-insulating water transporting vehicle is designed to solve the problem that water transported in cold area is apt to be frozen. The vehicle shall be actively heated and passively heat-insulated with fuel oil heater and polyurethane insulation layer. Furthermore, it also can be automatically heated with the special management system by controlling the heater according to the water temperature and the ambient temperature. In order to study on the heat-insulation property of the vehicle, the temperature distribution of the water in the tank and heat losses from the tank with ANSYS; finally, the low temperature environmental test is carried out. The test result shows that the water temperature in the tank is reduced from 20°C to 19°C for 24h under ambient temperature of -25°C, the average overall heat transferring coefficient is 0.52W/(m²•K) and thus completely meets requirements for water transporting in cold areas.

• Periodical: Applied Mechanics and Materials (Volumes 401-403)
• Pages: 362-366
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.401-403.362
• Online since: September 2013
• Authors: Cong Qi Xu, Gui Zhi Jia, Rui Lin Gao, Xi Bin Ma, Xian Wang
• Keywords: ANSYS, Heat Insulation Property, Heat Transferring Coefficient, Water Transporting Vehicle

References

[1] S. Morefield, J. Carlyle. Acoustic leak survey of the underground potable water system at a CONUS army installation, Advanced Materials Research. 38 (2008) 143-154.

DOI: 10.4028/www.scientific.net/amr.38.143

[2] D. Kroll, K. King. Laboratory and flow loop validation and testing of the operational effectiveness of an on-line security platform for the water distribution system, 8th Annual Water Distribution Systems Analysis Symposium. (2006).

DOI: 10.1061/40941(247)173

[3] V. Blaricum. Water Distribution. System Modeling and Remote Monitoring, Advanced Materials Research. 38 (2008) 132-142.

DOI: 10.4028/www.scientific.net/amr.38.132

[4] Renhong Liu, Structure of Heat-insulation Water Transportation Vehicle and Preparation of Heat-insulation Layer, Special Vehicles. (2007) 36-37. (In Chinese).

[5] Jinpu Chu, Xiaopeng Li and Shuhao Niu, et. al. Chinese Patent 200820149962. 3. (2008). (In Chinese).

[6] Wenjian Song, Jun Cao and Guodong Bao, et al. Chinese Patent 200820069280. 1. (2008). (In Chinese).

[7] Guizhi Jia, Congqi Xu and Ruilin Gao, et al. Chinese Patent 201310228622. 5. (2013). (In Chinese).

[8] TB/T 1537-1997 Test and Evaluation Method of Heat-insulation Property of Heat-insulation Vehicle , Ministry of Railways, Beijing, 1997. (In Chinese).
