Analysis on Fracture Accident of the Roll and Universal Joint

Abstract:

The fracture accident of roll and universal join are analyzed, and universal spindle forked joint with finite element analysis is analysed, the stress distribution and maximum stress value is obtained. In the impact power load caused by the roll biting stopping is calculated in detail, and the largest actual load and maximum stress in possible is calculated, explaining the cause of fracture of the important parts such as universal spindle forked joint, and putting forward the improvement opinion for the equipment design and using.

• Periodical: Applied Mechanics and Materials (Volumes 401-403)
• Pages: 65-68
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.401-403.65
• Online since: September 2013
• Authors: Xi Wang, Chang Liang Xu
• Keywords: Finite Element Analysis (FEA), Rolling Mill, Stress, Universal Joint

References

[1] Zou J.X., Rolling machinery[M]. Beijing, Metallurgical Industry Press. 2006. (in Chinese).

[2] Zou J.X., Modern design theory of rolling mill[M]. Beijing, Metallurgical Industry Press. 1991. (in Chinese).

[3] Zhu C.C., Qin D.T., He N.F., Liu J.Q. Research on breakage of rolling mill universal coupling[J]. Metallurgical Equipment. 2002, 2: 37-40. (in Chinese).

[4] Yao Z.H. Prognosis of crackle on universal coupling based on Kohonen network[J]. Machinery & Electronics. 2005, 8: 39-41. (in Chinese).

[5] Yao Z.H. Nervous network and diagnosis of breakdowns in universal joint axis of small-size roll[J]. Journal of Agricultural Mechanization Research. 2003, 4: 96-97. (in Chinese).
