Co-Simulation of Radar Antenna Azimuth Based on Adams and Simulink

Abstract:

Large antenna is susceptible to external influence in the actual work load; it causes the azimuth change and affects the radar work. In order to solve this problem, Adams and Simulink co-simulation method and the antenna board PID control are used. Simulation results show that angular variation of the callback can be achieved, and the response time can be greatly reduced less than 2 seconds. Keywords: Panel Antenna, Co-simulation, Azimuth control

• Periodical: Applied Mechanics and Materials (Volumes 401-403)
• Pages: 89-92
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.401-403.89
• Online since: September 2013
• Authors: Han Zhao, Guan Hong Wu, Wei Zong
• Keywords: Azimuth Control, Co-Simulation, Panel Antenna

References

[1] REN. Y, BAI. G. C: Mechatronics 15(6) (2009).

[2] WANG Z. L, Mat lab/Simulink and control system simulation, edited by Electronic Industry Press (Beijing) (2013).

[3] LI.Z. G, Adams introduction and detailed explanation, edited by National Defense Industry Press, (Beijing) (2013).
