Near-Infrared Spectroscopy Signal Extraction and Processing Design

Abstract:

This paper introduces the MSP430 MCU-based near-infrared spectrometer front-end signal extraction and software signal processing design.The system adopts phase locked loop technology to signal phase shift processing. Phase sensitive filtering function achieved by the balance modem AD630.Finally the analog signal is converted to digital signal by AD7715 for the microprocessor processed.Microprocessor receives digital signal, filter processing is performed using a first order lag filter method to determine the point of measurement value.Through the comparison analysis of the experimental testing result, the program has higher signal-to-noise ratio and suppress interference ability, high reliability, good stability,etc.

• Periodical: Applied Mechanics and Materials (Volume 404)
• Pages: 555-559
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.404.555
• Online since: September 2013
• Authors: Ke Zhao, Jian Hua Jiang, Jun Fang Fu, Jin Bo Xu
• Keywords: First Order Lag Filter, Near Infrared Spectroscopy (NIRS), Phase Locked Loop Amplification

References

[1] Yong Huang, Shuqun Zhang, Develop of Near-Infrared Spectrometer Base on ARM Embedded-system [J]. Development and application of the Arm, 2008(11). (In Chinese).

[2] Zhengan Jia, Peipei Zhang. Research on Near-Infrared Spectrum Detecting Circuit with LIA[J]. Instrument technique and sensor. 2012(4). (In Chinese).

[3] Zhuo Xu, Lei Yang. The Application of AD7715 in the Multi-channel Thermal Resistance Measurement [J]. Electrical and instrument measurement. 2012(4). (In Chinese).

[4] Ke Zhao, Ming Zhao. Rapid non-destructive testing of navel orange based on near-infrared spectroscopy [J]. Laser and infrared. 2011(6) . (In Chinese).

[5] Qin Bo. Houlai Yan. Design and implementation of software system for near-infrared spectroscopy acquiring and processing [J]. Experimental technology and management. 2010 (5). (In Chinese).

[6] LiuY.D. ，LuoJ，Chen X.M. Analysis of soluble solid content in Nanfeng mandarin fruit with visible near-infrared spectroseopy[J]. Journal of Infrared and Millimeter Waves，2008，27(2): 119一122.

DOI: 10.3724/sp.j.1010.2008.00119

[7] Binliang Jiao, Sujing Li. lock-in amplifier and its correlation detection thorough analysis [J]. Journal of electronic technology. 2008 (1). (In Chinese).

[8] Baoying Jin, Maoseng Bai, Fengming Sun. Design of signal processing circuit of laser ultrasonic based on phase lock-in amplifier technology [J]. Journal of sensors and micro system. 2012 (3). (In Chinese).

[9] Xiaoliang Chen, Yangdong Deng, Xiaobing Cheng. High Speed FIR Digital Filtering on GPU [J]. Journal of computer-aided design and graphics. 2010 (9)(In Chinese) . (In Chinese).

[10] J. Craninckx, M. Steyaert. Kluwer. Wireless Cmos Frequency Synthesizer Design[M]. Academic Publishers, (2007).
