Analysis of Cement Emulsified Asphalt Mortar Gap on CRTSII Slab Track under Train Loading

Abstract:

The finite element method was used to analyze the deformation and stress of track in different length and height of gaps under the train load. In order to study the influence of gap between the slab and emulsified cement asphalt mortar of china railway track system II slab track on the subgrade, a model of CRTS II slab track was established on the base of elastic foundation beam theory and finite element software ANSYS. The results show that gap between slab and CA mortar has significance effect on the stress and deformation of track structure. The deformation of rail and slab, the longitudinal stress of slab were increase with the increase of gap length, but has less effect on lateral stress of slab. When the length of gap exceed to 1.95m, the deformation and stress have the tendency of increase sharply, the length of gap between slab and CA mortar should not exceed 1.95m. The gap between slab and CA mortar has effect on the durability and lifetime of ballastless track, so the gap should be maintenance timely.

• Periodical: Applied Mechanics and Materials (Volumes 405-408)
• Pages: 1834-1838
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.405-408.1834
• Online since: September 2013
• Authors: Hao Xu, Ping Wang, Jing Mang Xu
• Keywords: China Railway Track System II Slab Track, Deformation, GaP, Maintenance

References

[1] J. Xu, Z.H. Chen, K. Wang, Y. Yang: Journal of East China Jiaotong University, Vol. 26 (2009) No. 5, pp.58-62(in chinese).

[2] T. Wang. Research and application on CA mortar in ballastless slab track of high speed railway(Ph.D., Wuhan University of Technology, China 2008, pp.11-12 (in chinese).

[3] Y.Q. Wei. Research on cement emulsified asphalt mortar in ballastless slab track of high speed railway(Master., Chang'an University, China 2010, pp.5-9 (in Chinese).

DOI: 10.1061/9780784412299.0065

[4] S.H. Jin, X.F. Chen, J.Y. Yang: China Railway Science, Vol. 26 (2006) No. 2, pp.20-25(in chinese).

[5] J. Xiang, D. He: Journal of Traffic and Transportation Engineering, Vol. 7 (2007) No. 3, pp.1-5 (in chinese).

[6] M.X. Li. Parameters research of longitudinally connected ballastless track on bridge of high speed railway(Master., Central South University, China 2009, pp.20-42 (in chinese).

[7] P. Xu, C.B. Cai: Journal of Southwest Jiaotong University, Vol. 46 (2011) No. 2, pp.189-194 (in chinese).

[8] X.L. Song, W.M. Zhai: China Railway Science, Vol. 33 (2012) No. 4, pp.1-7 (in chinese).

[9] X.Y. Liu, P.R. Zhao, R.S. Yang, P. Wang. The design theory and method for ballastless track on passenger dedicated line[M]. Southwest Jiaotong University Press, (2010), Chengdu (in chinese).

[10] P. Wang, H. Xu, R. Chen, J.M. Xu: Journal of Southwest Jiaotong University, Vol. 47 (2012) No. 6, pp.929-934 (in chinese).
