Based on Inclinometer to Measure Dynamic Deflection of High-Speed Railway Bridge

Abstract:

The dynamic deflection measurement is an important component to the bridge loading test of high-speed railway bridge. Using inclinometers to test the Dynamic deflection is a good method for High-Speed Railway bridge deflection detection. In this paper, we develop a new inclinometer and a new theory to fast calculate deflection. It has been use to detect the dynamic deflection of Baishui River bridge on FuZhou-WenZhou High-Speed Railway when high speed train runs across at kinds of speed. Results indicate: comparing with the measurement results of photoelectric deflection detection system, all dynamic deflection measurement results of inclinometers are very accuracy. Their deflection curves are also similar. All results also show: Using our inclinometers to test High-Speed Railway bridge dynamic deflection can get precise results and can satisfy the dynamic deflection measurement request of high-speed railway bridge. Comparing with other methods of dynamic deflection measurement, this method is very easy to operate., do not need stop the traffic, and not affected by weather, and not need a static reference point, can measure the dynamic deflection of any beam bridge.

• Periodical: Applied Mechanics and Materials (Volumes 405-408)
• Pages: 3019-3026
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.405-408.3019
• Online since: September 2013
• Authors: Xian Long He, Li Zhen Zhao
• Keywords: Dynamic Deflection, High-Speed Railway Bridge, Inclinometer, Measure Deflection, Photoelectric Deflection Detection

References

[1] Zhou Zhengxiang. Comparing with several ways of bridge deflection testing[J]. Road Journal, 1995. 46(7): 20-25.

[2] Yang Xuanshan. Engineering vibration testing and devices technology[M]. Chinese measure press. (2001).

[3] Charles W. Roeder. The report of improving live load deflection criteria for steel bridges[c]. University of Washington. (2002).

[4] Xianlong He, Tianli She, Lizhen Zhao. A New System for Dynamic Deflection Measurement of Highway Bridge. Applied Mechannics and Matericals. Vols. 226-228(2012)pp.1645-1650.

DOI: 10.4028/www.scientific.net/amm.226-228.1645

[5] QI Fangxiao. Dynamic Response of Railway[M]. Science and technology press. (2007).

[6] Xianlong He. The research on bridge deflection and slope angle monitored with Servo-slope sensor [M]. Herbin: china earthquake press. (2012).

[7] Yang Xuanshan. A new way for bridge deflection measurement[J]. Civil engineering journal, 2002, 35(2): 92–96.

[8] Yang Xuanshan. The research on inclinometer transient reacted [J]. Earthquake Engineering and Engineering Vibration, 2002, 22(2): 97–100.
