Hydraulic Characteristic Analysis of 3-Arcs Blades Surface in the Centrifugal Pump

Abstract:

According to the shape of 3-arcs blade the distribution function equations on 3-arcs blade surface were deduced and the hydraulic characteristics on blade surface were analyzed. Based on the establishment of relative velocity and pressure equations, the step change equations of relative velocity and pressure on blade surface were also deduced on connected line which was formed by the intersection of two cambered surfaces, and the reason and the relationships between control parameters were revealed. The step change value of relative velocity is equal to diameter difference of two intersect arc cylinders. The step change value of pressure is concerned with the position coordinates of initial origin of two intersect arc cylinders. Calculation example confirmed that the step changes of relative velocity and pressure will appear on intersection of two cambered surface.

• Periodical: Applied Mechanics and Materials (Volumes 405-408)
• Pages: 3269-3274
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.405-408.3269
• Online since: September 2013
• Authors: Yu Lin, Hui Li, Shu Ren Han
• Keywords: Arc, Blade, Cylinder, Hydraulic Characteristics

References

[1] Ma Jiesheng, Xue XueGong, Li Wei. The theory of 3-arcs blade's shape and the performance test of pump[J]. Colored equipment, 2003, NO1: 19-20.

[2] Guan Xing Fan. the modern pump technology Manual [M]. Beijing: Astronautics Press, (1995).

[3] Ding Cheng Wei. The principle and hydraulic design of centrifugal pump and propeller pump [M] Beijing: Mechanical Industry Press, (1981).

[4] Wang Xian Fu, Xiong Ao Kui. Advanced Fluid Mechanics[M]. Wuhan: Huazhong University of Science and Technology Press, (2004).

[5] Zhang Kewei. Fluid mechanical principles (First Volume) [M]. Beijing: Machinery Industry Press, (2006).
