Detection Citrus Fruits with Shadow within Tree Canopy by Image Fusion Method

Abstract:

In order to guide the robots for harvesting citrus fruits, method based on normalized RGB model and chromatic aberration map was developed to detect citrus fruits with shadow within tree canopy. Several images of natural citrus-grove scene were photoed, and the color properties of target objects were analyzed. A rule for segmenting citrus fruits from background was put forward by fusing the segmented results of the normalized R channel map and the chromatic aberration map of R and B channels. The results show that the fruits with shadow can be detected integrally using the proposed method.

• Periodical: Applied Mechanics and Materials (Volumes 411-414)
• Pages: 1330-1334
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.411-414.1330
• Online since: September 2013
• Authors: Jun Lu, Nong Sang, Ren Yuan Liang, Lin Chai
• Keywords: Chromatic Aberration Map, Image Fusion, Normalized R Channel Map, Shadow Detection

References

[1] R.C. Harrell， D.C. Slaughter: Machine Vision& Appli．Vol. 2(1989), pp.69-80.

[2] D.C. Slaughter， R.C. Harrell: Trans of the ASAE，vol. 32(1989), pp.757-63.

[3] G. M. Grasso, M. Recce. Scene analysis for an orange picking robot, Proceedings for 6th International Congress for computer technology in agriculture (ICCTA'96), The Netherlands, pp.275-280.

[4] Y.A. Ness, Computer vision system for all orange harvesting robot[D]．Haifa，Israel：Department of Mechanical Engineering， Technion - Israel Institute of Technology，1989.

[5] E. Moct, F. Pla, F. Juste: Journal of Agricultural Engineering Research, Vol. 59(1992), pp.101-110.

[6] H.R. Xu，Z.Z. Ye，Y.B. Ying: Transactions of the CSAE，Vol. 21(2005), pp.98-101．(in Chinese with English abstract).

[7] Y.J. Zhang, L. Deng, M.Z. Li: Transactions of the Chinese Society for Agricultural Machinery, Vol. 40(2009), pp.97-99. ( in Chinese).

[8] J.H. Wang, Q. Ouyang, Q.S. Chen: Optics & Optoelectronic Technology, Vol. 7(2009), pp.56-58, 62. ( in Chinese).

[9] J.R. Cai, Y.L. Li, J. Fan, et al.: Microcomputer Information, Vol. 23(2007), pp.224-226. ( in Chinese).

[10] J.R. Cai, X.J. Zhou, Y.L. Li, et a1.: Transactions ofthe CSAE，Vol. 24(2008), pp.175-178．(in Chinese with English abstract).

[11] J. Lu, J.J. Chen, P.F. Wu, et al : Transactions of the CSAE, Vol. 28(2012), p.269－274. (in Chinese with English abstract).

[12] R.C. Gonzalez, R.E. Woods. Digital Image Processing[M], Second Edition, Prentice Hall, 2002, 611.

[13] Milan Sonka, Vaclav hlavac, Roger Boyle. Image Processing, Analysis, and Machine Vision, Second Edition[M]. Thomson Press, 2002, 586.

DOI: 10.1117/12.256634

[14] X.J. JING, A.N. CAI, J.A. SUN.: Journal of China Institute of communications. Vol. 22(2001), pp.71-76. (in Chinese with English abstract).

[15] N. OTSU: IEEE Trans on Systems, Man and Cybernetics. Vol. 62(1979), pp.62-69.
