The Modeling Gear Optimization Design Research Based on Pro-E

Abstract:

With the development of computer technology, gear modeling in industry more and more widely used, the PRO-E tool has good modeling function, on the design of three-dimensional CAD tools has a significant role, the tracing point method, parameter method, plug-in method analysis, optimum gear profile modeling. On the tooth height model modification method, draw gear high maximum model modification, model modification can be assigned in the active or passive gear wheel tooth, but also at the same time in the driving wheel and a driven wheel model modification. Corresponding to a single tooth meshing zone involute not model modification, only to repair the dual meshing zone, reach the gear model optimization objective.

• Periodical: Applied Mechanics and Materials (Volumes 411-414)
• Pages: 452-457
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.411-414.452
• Online since: September 2013
• Authors: Zhe Ming
• Keywords: Gear, Modeling, Optimization, Pro/E

References

[1] ChengLiang fei, ZhangFu sheng, GaoXiao juan. On Hypoid Gear Parameterization of 3D based on Modeling Pro/Toolkit Asynchronous Mode about. [J]. Taiyuan University of Science and Technology Journal, 2012, (1): 45-49.

[2] WangXiao lin, XieGang, MaXue jie. CAD Program Development's Parametric Design on Hypoid Gear [J]. Mechanical Drive, 2005, 29(4): 23-25, 33.

[3] LiJing kui, JingYing yi. On SoildWorks Design of Parametrization [J]. Tianjin University of Technology Journal, 2009, 25(4): 26-28.

[4] QiaoXiao yan, FuYu, WangJun. On Die Part Parametric Design Secondary Development Based on Pro/E [J]. Die Industry , 2007, 33(12): 8-13.

[5] DingQi zhi, FuJing hong. Parametrization Design and Drawing Based on VBA[J]. Mechanical Drive, 2004, 28(5): 38-39, 37.
