The Functional Design on Fault Recorder of μC/OS-II-Based Intelligent Substation

Abstract:

Regarding the functional requirements for smart substation in fault recorder, this paper introduced μC / OS-II, an embedded real-time multitasking operating system as the functional design. The program works with the embedded operating system, the state machine theory and new methods for embedded development, whilst tasking full use of the advantages of such functions as task scheduling, message queues, etc., aiming to achieve a fault recorder function of intelligent substation. More than taking care of the difficulty of programming, it could improve the program reliability and portability. The program has been applied in an intelligent substation protection in centralized control unit, which has brought back a good fault recorder performance. On this basis, more functions can be integrated, including network log analysis, state estimation, etc., in order to truly meet the application requirements of the smart substations.

• Periodical: Applied Mechanics and Materials (Volume 415)
• Pages: 209-215
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.415.209
• Online since: September 2013
• Authors: Yi Hui Zhang, Wen Qiang Hu, Shi Ming Liu, Hua Bing Wang
• Keywords: Embedded Operating Systems, Fault Recorder, Intelligent Substation, State Machine, μC⁄OS-II

References

[1] LUO Jian, DING Wang lin, TANG Tao. Comparison of Domestic and Foreign Fault Recorders. Electric Power Automation Equipment[J], 2001, 21(7): 27-31.

[2] CHEN Haolin, ZHANG Guoqing, GUO Zhizhong. Development and present situation analysis of fault recorder[J]. Power System Protection and Control, 2010, 38(5): 148-152.

[3] Q/GDW 383. Technical guide for smart substation[S], (2009).

[4] ZHANG Peichao, GAO Xiang. Smart Substation [J]. Electrical Engineering, 2010, 8: 4-10.

[5] CHANG Fengran, XIAO Yan, ZHANG Hong, ZHAO Chunlei. Research and practice of wave recording scheme for smart substation[J]. Electric Power Automation Equipment, 2011, 31(1): 109-112.

[6] YANG Tingfang, LIU Pei. Design of An Integrated Fault Recorder Based on Industrial Controlling Computer[J]. Electric Power Automation Equipment, 2001, 21(6): 26-29.

[7] ZHANG Yandong, JIAO Yanjun, ZHANG Ju. Design of fault recorder based on embedded system[J]. Electric Power Automation Equipment, 2004, 24(10): 61-64.

[8] KANG Zhongjian, LI Haifeng, CHEN Jie, GUO Zhizhong. Design of fault recorder based on dual embedded operating systems[J]. Electric Power Automation Equipment, 2006, 26(1): 61-64.

[9] FU Guoxin, DAI Chaojin, SHI Changjiang, ZHANG Mingyong. Design of intelligent substation fault recorder[J]. Electric Power Automation Equipment, 2010, 30(7): 3.

[10] Jean J. Labrosse. MicroC/OS-II The Real-Time Kernel, Second Edition [M]. USA: CMP Books, (2002).

DOI: 10.1201/9781482295603
