Detection and its Application of Real-Time Rotor Position with High-Precision for Switched Reluctance Motor Drive

Abstract:

It is very important to detect the accurate rotor position of switched reluctance motor (SRM) for a high-performance switched reluctance motor drive. And, there are two main factors to influence SRMs rotor position detection, which are the accuracy of the position signal and the controllers real-time response. It cant meet the accuracy requirements to detect shaft position information by opto-couplers, so absolute encoder is used to produce the high-precision rotor position signal. Moreover, the all-digital controller based on DSP and CPLD achieves the real-time detection and applications of high-precision rotor position signal on SRM, with their strong ability on data processing and hardware logic describing. Due to adopting high-precision rotor position detection and control, it carries out successfully and improves the system performance. The experimental results show that the design is reliable and effective, which has great significance for the establishment and realization of high-performance SRM drive.

• Periodical: Applied Mechanics and Materials (Volume 415)
• Pages: 227-231
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.415.227
• Online since: September 2013
• Authors: Yan Cai, Yan Bin Wen, Chen Hui Wang, Shao Xiong Fan, Wen Tao Jiang
• Keywords: Absolute Encoder, Complex Programmable Logic Device (CPLD), Digital Signal Processor (DSP), Rotor Position, SRM

References

[1] K. Vijayakumar, R. Karthikeyan, S. Paramasivam, R. Arumugam, K.N. Srinivas, Switched Reluctance Motor Modeling, Design, Simulation, and Analysis: A Comprehensive Review, ，IEEE Transactions on Magnetics, vol. 44, no. 12, pp.4605-4617, (2008).

DOI: 10.1109/tmag.2008.2003334

[2] X. D. Xue, K. W. E. Cheng, J. K. Lin, et al, Optimal Control Method of Motoring Operation for SRM Drives in Electric Vehicles, IEEE Transactions on Vehicular Technology, vol. 59, no. 3, pp.1191-1204, (2010).

DOI: 10.1109/tvt.2010.2041260

[3] R. Cardenas, R. Pena, M. Perez , J. Clare , G. Asher, P. Wheeler, Power Smoothing Using a Flywheel Driven by a Switched Reluctance Machine, IEEE Transactions on Industrial Electronics, vol. 53, no. 4, pp.1086-1093, (2006).

DOI: 10.1109/tie.2006.878325

[4] Jin-Woo Ahn, Sung-Jun Park, Dong-Hee Lee, Novel encoder for switching angle control of SRM, IEEE Transactions on Industry Applications, vol. 53, no. 3, pp.1726-1731, (2006).

DOI: 10.1109/tie.2006.874278

[5] Shuanghong Wang, Qionghua Zhan, Zhiyuan Ma, Libing Zhou, Implementation of a 50-kW Four-Phase Switched Reluctance Motor Drive System for Hybrid Electric Vehicle, IEEE Transactions on Magnetics, vol. 41, no. 1, pp.501-504, (2005).

DOI: 10.1109/tmag.2004.838985

[6] S. Orlosky, Basics of rotary optical encoders, Control Engineering, vol. 44, pp.72-82, (1997).

[7] S. Wekhande, V. Agarwal, High-resolution absolute position vernier shaft encoder suitable for high-performance PMSM servo drives, IEEE Transactions Instrumentation and Measurement, vol. 55, no. 1, pp.357-363, (2006).

DOI: 10.1109/tim.2005.862020

[8] Xiaoli Cheng, Jianying Xie, Lin Wang, Application of Absolute Encoder to Motor Position Detection Systems, Control Engineering of China, vol. 14, no. 5, pp.548-550, (2007).
