A Novel Method on Real-Time Measurement of 2-DOF Motions of Spherical Ultrasonic Motor

Abstract:

Spherical ultrasonic motor (SUSM) is utilized primarily in the assembly sectors, precision machining and active tracking devices. The controllability and accuracy of the SUSM are much concerned in those practical uses. So the sensors which measure the motion of the stator are usually used to build up a closed loop control system. These sensors can detect the position and speed of the ball stator. However, the traditional contact positional detection device which contains photoelectric encoders has the disadvantages of low measuring precision. A novel contactless method which based on an optical sensor, is introduced in the paper. A further illustration including principles of the method, the model of 2-DOF motion of the spherical ultrasonic motor rotor, a set of experiment test-bed to verify the feasibility of the method are presented in the article. The experiment turns out an expectant result and shows the method feasible and significant for application.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 1080-1085
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.1080
• Online since: September 2013
• Authors: Zhe Guo, Yang Bai, Lin Yi, Ji Feng Guo, Jian Wang
• Keywords: Contactless Sensing, Displacement, Loop Control, Spherical Ultrasonic Motor

References

[1] Lim, Chee Kian , Chen, I-Ming, Yan, Liang, Luo, Zhiqiang A novel approach for positional sensing of a spherical geometry Source: Sensors and Actuators, A: Physical, v 168, n 2, pp.328-334, August 10, (2011).

DOI: 10.1016/j.sna.2011.04.035

[2] Development of a Spherical Ultrasonic Motor with an Attitude Sensing System using Optical Fibers 2007 IEEE International Conference on Robotics and Automation Roma, Italy, 10-14 April (2007).

DOI: 10.1109/robot.2007.364167

[3] Tomoaki mashimo, Member, IEEE, shigeki Toyama, and Hiroshi Ishida, Member, IEEE Design and Implementation of Spherical Ultrasonic Motor, IEEE Transactions on Ultrasonics, Ferroelectrics, and Frequency control, vol. 56, no. 11, November (2009).

DOI: 10.1109/tuffc.2009.1338

[4] Fu, Ping (Minjiang University, Fuzhou 350108, China); Guo, Jifeng; Shen, Runjie; Shuai, Guangju; Cai, Ping Operation mechanism and characteristic of spherical two degree-of-freedom traveling-wave type ultrasonic motor Source: Diangong Jishu Xuebao/Transactions of China Electrotechnical Society, v 24, n 4, pp.42-47, April (2009).

[5] ADNS-5030 datasheet.
