Structural Optimization of Double-Secondary PMSLM Based on Spatial Harmonic Suppression

Abstract:

In view of that detent force (DF) spatial harmonic has great influence on thrust ripple of permanent magnet synchronous linear motor (PMSLM), a harmonic suppression method is proposed. DF of the PMSLM model is calculated by finite element method (FEM) and its harmonic spectrum is achieved by Fourier transform (FT). Also total harmonic distortion (THD) is introduced to quantificat spatial harmonic. The effects of air gap, permanent magnet (PM) size, primary size, secondary size and pole-arc coefficient upon DF are analyzed. In order to minimize THD, orthogonal optimization design is adopted to optimize PMSLM structural parameters. A double-secondary PMSLM is chosen as the subject of research in the paper. Based on quantitative calculation, orthogonal experiment and range analysis are used to obtain optimal structures. This paper provides an effective quantitative analysis method for PMSLM spatial harmonic suppression.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 1251-1256
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.1251
• Online since: September 2013
• Authors: Pan Pan Chen, Ji Wen Zhao
• Keywords: Double-Secondary PMSLM, Spatial Harmonic Suppression, Structural Optimization, THD

References

[1] C. Lianfeng, and H. Yuli, Thrust fluctuations optimal design of PMALM for machine tool, in Micromotors, vol. 45, No. 10, pp.29-33, Oct. (2012).

[2] P. Kailin, F. Jianzhong, and C. Zichen, Detent force analysis and reduction of PMLSM, in Proceedings of the CSEE, vol. 24, No. 4, pp.112-115, Apr. (2004).

[3] L. Honghao, and L. Zili, Harmonic analysis and minimization of cogging torque in permanent magnet motors, in Electric Machines and Control, vol. 14, No. 4, pp.36-40, Apr. (2010).

[4] H. Yuping, W. Hongxing, and L. Liyi, Research on detent force of permanent magnet linear synchronous motor with moving magnets, in Micromotors, vol. 43, No. 6, pp.28-31, (2010).

[5] L. Qinglei, W. Xiankui, W. Dan, and L. Chengying, Thrust fluctuation analysis and reduction of PMSLM, in Journal of Tsinghua University, vol. 40, No. 5, pp.33-36, (2000).

[6] B. Grcar, P. Cafuta, and G. Stum Berger, Control-based reduction of pulsating torque for PM AC machine, in IEEE Transactions on Energy Conversion, vol. 17, No. 2, pp.169-175, (2002).

DOI: 10.1109/tec.2002.1009464

[7] Y. Peiqiong, L. Sheng, F. Jiangzhong, and C. Zichen, Analysis and reduction of detent force in permanent magnet linear synchronous motor, in 2004International Conference on Computational Electromagnetics and Its Applications Proceedings, pp.525-528.

DOI: 10.1109/iccea.2004.1459408

[8] L. Liyi, M. Tao, L. Xiaopeng, and Z. Yanli, A study of cogging force in linear permanent magnet motor, in Micromotors, vol. 39, No. 4, pp.28-30, (2006).

[9] L. Honghao, W. Jun, and C. Wensen, Minimization of cogging force in moving magnet type PMBLDCLM, in Proceedings of the CSEE, vol. 27, No. 6, pp.12-16, Feb. (2007).

[10] C. Jiujian, M. Wenli, and H. Jinlong, Detent force analysis and reduction of bilateral PMLSM, in Small & Special Electrical Machines, vol. 40, No. 6, pp.1-7, (2012).

[11] W. Hao, Z. Zhijing, and L. Chengying, Detent force analysis and experiment for permanent magnet linear synchronous motor, in Proceedings of the CSEE, vol. 30, No. 15, pp.58-63, May. (2010).

DOI: 10.1109/mace.2010.5535740

[12] D. Weimin, Research on electromagnetic design and detent force of permanent magnet linear motor, " Jiaozuo: Institutes of Technology of He, nan, pp.11-18, (2009).

[13] H. Lati, and Y. Huadong, On use of orthogonal experimental design, in Acta Editologica, vol. 17, No. 5, pp.334-335, Oct. (2005).
