Study of Power System Protection Devices Based on Automation Open Hardware Platform

Abstract:

Protection devices must recognize the errors in electricity supply network and separate the fault from the rest of the supply network, which is determined by comparing actual to adjusted intensity of voltages and currents. In order to realize the interchange of electrical protection devices, it should be developed on the basis of open hardware platforms. In this work, over currents time protection relay will be implemented on programmable logic controller and tested.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 721-726
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.721
• Online since: September 2013
• Authors: Bin Cai
• Keywords: Hardware Platform, Over Current, Programmable Logic Controller (PLC), Protection Device, Supply Network

References

[1] WANG Gang, DING Mao-sheng, LI Xiao-hua, XIAO Lin. Reliability analysis of digital protection[J]. Proceedings of the Chinese Society for Electrical Engineering, 2004, 24(7): 47-52.

[2] WU Guo-yang, SONG Xin-li, TANG Yong, ZHONG Wuzhi, et al. Protection relay modeling for dynamic simulation of power systems[J]. Automation of Electric Power Systems, 2010, (23): 64-70.

[3] Otto, A., Hellmann, K. IEC 61131: A general overview and emerging trends[J]. Industrial Electronics Magazine, IEEE, 2009, 3(4): 27-31.

DOI: 10.1109/mie.2009.934793

[4] Carlsson, H., Svensson, B., Danielsson, F., Lennartson, B. Methods for reliable simulation-based PLC code verification[J]. IEEE Transactions on Industrial Informatics, 2012, 8(2): 267-278.

DOI: 10.1109/tii.2011.2182653

[5] GAO Chun-ru, ZHANG Jin-shui, ZHAO Xu-dong, SHEN Jian. Setting calculation of negative sequence overcurrent protection for high-voltage motor[J]. Automation of Electric Power Systems, 2011, 35(15): 93-97.

[6] CAO Wen-si, GUO Heng, GONG Lu-hong, QIU Dao-yin. Parameter optimization of protection circuit for operation controller of permanent magnetic actuator with vacuum circuit breaker[J]. Electric Power Automation Equipment, 2011, 31(11): 83-88.

[7] Kim, J.S., Lim, S.H., Kim, J.C. Study on protection coordination of a flux-lock type SFCL with over-current relay[J]. IEEE Transactions on Applied Superconductivity, 2010, 20(3): 1159-1163.

DOI: 10.1109/tasc.2010.2045749

[8] Durocher, D.B., Walls., Becker, S. Understanding circuit breaker design and operation to improve safety and reliability in underground mining[J]. IEEE Transaction on Industry Applications, 49(1): 3-9.

DOI: 10.1109/ias.2011.6074388
