Dynamic Modeling and Tracking Control Simulation for Large Electro-Hydraulic Servo System

Abstract:

The co-simulation method of one large electro-hydraulic servo system based on software interface is proposed in this paper. The rigid-flexible-coupling dynamic model of the electro-hydraulic servo mechanism was built through data exchange of SolidWorks, ANSYS and ADAMS, the hydraulic system model and control system framework was built by EASY5 environment, the controller was built by Simulink. The integration of simulation models for the large electro-hydraulic servo system was realized by software interfaces. In view of the poor operation conditions, the high requirement of control precision and real-time characteristics, adaptive fuzzy sliding mode control strategy was applied to position tracking control of the servo system. Simulation results verified the effectiveness of this method.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 811-816
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.811
• Online since: September 2013
• Authors: Feng Li, Kai Wang, Cheng Li Ma, Jie Yu
• Keywords: Adaptive Fuzzy Slide Mode Control, Co-Simulation, Dynamic Modeling, Electro-Hydraulic Servo System, Position Tracking

References

[1] Gong Su-sheng, Xu Chang-sheng. Research on Rigid-Flexible Multiply Model Dynamic Simulation of the Portal Crane [J]. Journal of Wuhan University of Technology, 2012(4): 419-420. (in Chinese).

[2] Zhang Lin. The Optimizing Analysis of Flexible Body for New Type of Engine with Multi-connecting Rod Mechanism [D]. Tianjin: Tianjin University, 2006: 34-35. (in Chinese).

[3] Huang Xian-xiang, Gao Qin-he, Guo Xiao-song. Dynamic Modeling of Erected Process for Large Mechanism [J]. Journal of System Simulation, 2002, 14(3): 271-273. (in Chinese).

[4] Shen Jun, Song Jian. ADAMS and Simulink Co-simulation for ABS Control Algorithm Research [J]. Journal of System Simulation, 2007, 19(5): 61-63. (in Chinese).

[5] Li Jiang-bo，Huang Ming-hui，Zhao Xing. Co-simulation of a die forging press based on ADAMS and EASY5 [J]. Machinery Design & Manufacture, 2011(6): 236-237. (in Chinese).

[6] Liu Jin-kun, Advanced Sliding Mode Control for Mechanical Systems [M]. Beijing: Tsinghua University Press, 2011: 180-182.

[7] Guan Cheng, Zhu Shan-an. Derivative and Integral Sliding Mode Adaptive Control for a Class of nonlinear System and its Application to an Electro-hydraulic Servo System [J]. Proceedings of the CSEE, 2005(2): 104-107. (in Chinese).
