Phase Plane Analysis of Battery Series Balancing on Robot

Abstract:

The energy in rechargeable batteries of robots was restricted by its capacity and chemistry combination. Since the energy was limited, the way to manage batteries charging/discharging characteristic and how it applies on robots load become crucial to prolong robots working hours and life. Phase Plane Analysis of Battery Series Balancing on Robot is proposed by switching super capacitor according voltage and current in need for batteries with matrix connection. To take servo motors frequently load shock characteristic in concern, the proposed structure able to absorb and release power instantly since the characteristic of super capacitor has a better performance than Lithium batteries.

• Periodical: Applied Mechanics and Materials (Volume 418)
• Pages: 29-33
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.418.29
• Online since: September 2013
• Authors: Yu Chang Chang, Sheng Chen, Chih Chen Chen
• Keywords: Lithium Batteries, Phase Plane, Super-Capacitor (SC)

References

[1] S. Chen, C. K. Wang, and H.P. Huang, Intelligent Cell-balance Algorithm with Pseudo-series Connected Battery on the Security Robot, The 6th Taiwan Power Electronics Conference & Exhibition（TPECE 2007）, Sep. 7th, (2007).

[2] C. K. Wang, Sheng Chen, and Han Pang Huang., Realistic Implementation of Inductance Recharging System with Intelligent Cell-balance Algorithm on the Humanoid Robot, International Journal of Fuzzy System, Vol. 10, No. 1, March 2008 . (EI).

[3] C. K. Wang, S. Chen, and H.P. Huang, Visualized Human - Mchine Interface of the Power Management System on the Safeguard Robot, The Ninth International Conference on Automation Technology Automation 2007, June 13-14th, (2007).
