Motion Planning of the Mobile Robot Using Laser Detection System

Abstract:

The paper programs motion paths using laser detection system for the mobile robot. The laser detection system contains a laser range finder and a laser positioning system. The mobile robot is constructed using aluminum frame, and has the shape of cylinder and its diameter, height and weight is 40 cm, 80cm and 40kg respectively. In the driver system and avoidance obstacle driver system, we use NI motion control card and MAXON drivers to control two DC servomotors, and detect obstacle using a laser range finder and sixteen reflective IR sensors. The mobile robot locates the position of the detected obstacles using a laser positioning system. The mobile robot can program the motion path using A* searching algorithm and avoids the detected obstacles to follow the programmed trajectory. We develop the user interface to display the positions of the detected obstacles. Finally, we implement the experimental results using the proposed method. The mobile robot moves to the target position from the start position autonomously. The mobile robot detects environment status using the laser detection system and avoids the detected obstacles to finish the assigned tasks.

• Periodical: Applied Mechanics and Materials (Volume 418)
• Pages: 48-51
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.418.48
• Online since: September 2013
• Authors: Jr Hung Guo, Bo Yi Li, Shih Ping Lin, Kuo Lan Su
• Keywords: A* Searching Algorithm, Laser Positioning System, Laser Range Finder, MAXON Drivers, NI Motion Control Card

References

[1] K.L. Su, Y.L. Liao and C.Y. Chung, Path Planning of Mobile Robots Using Laser Range Finder, Journal of Science and Innovation, Vol. 2, No. 3(2012), p.139.

[2] K.L. Su, C.Y. Chung, J.T. Tzou and T.Y. Hsu, A* Searching Algorithm Applying in Chinese Chess Game, International Journal on Artifical Life and Robotics, Vol. 16, No. 2(2011), p.132.

[3] J. Minguez and L. Montano, Nearness Diagram (ND) Navigation: Collision Avoidance in Troublesome Scenarios, " IEEE Transaction on Robotics and Automation, Vol. 20 (2004), p.45.

DOI: 10.1109/tra.2003.820849

[4] H. Kobayashi, and M. Yanagida, Moving Object Detection by An Autonomous Guard Robot, IEEE International Workshop on Robot and Human Communication(1995), p.323.

DOI: 10.1109/roman.1995.531980

[5] Y. Shimosasa, J. Kanemoto, K. Hakamada, H. Horii, T. Ariki and Y. Sugawara, Some Results of The Test Operation of a Security Service System With Autonomous Guard Robot, IEEE International Conference on Industrial Electronic, Control, and Instrumentation(2000).

DOI: 10.1109/iecon.2000.973184
