The Simulation of the Launching Process on Concentration Water Injection Launcher

Abstract:

Simulation of the launching process in concentration water injection launcher, and get the parameter variations during the launch process, compared with traditional engineering algorithm, verify the reliability of the simulation results, given a new research method of interior ballistics on this launch system. This simulation has very important meaning for the temperature and pressure checking at the Beginning of the design. The simulation results show that,after the flow field stable,the average temperature and pressure in low-pressure chamber and the sabot are very close. This article uses the FLUENT software, use Mixture two-phase flow calculation model to solve the gas-liquid flow field, use the dynamic mesh and UDF program to simulation the flow field.

• Periodical: Applied Mechanics and Materials (Volume 419)
• Pages: 186-191
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.419.186
• Online since: October 2013
• Authors: Xiao Fei Zhou, Yi Jiang, Yu Sen Niu, Shao Zhen Yu
• Keywords: Dynamic Mesh, Flow Field Distribution, Interior Ballistic, Two-Phase Flow, Udf, Vaporization

References

[1] LIU Yongquan, XI Anmin, LIU Hongfei. Missile gas - steam catapult launch technology overview. Cruise missile [J], (2009).

[2] BAO Tingyu, QIU Wenjian. interior ballistics [M]. Beijing: Beijing Institute of Technology, (1995).

[3] SHEN Guo. Numerical Simulation and Parameter Design on Steam-powered Catapult [D]. Nanjing Institute of Technology, (2010).

[4] ZHANG Renjun. The CAD Development for Interior Ballistic Design of Gas-steam Launching Power System with Water Injection in Block [D]. Northwestern Polytechnical University, (2005).

[5] MA Yanli, JIANG Yi, WANG Weichen, YAN Feng, HAOJiguang. Research on Launching Process Cooling Effect of Wet Concentric Canister Launcher [J]. JournalofBallistics, (2010).

[6] LI Renxian. The basis of the finite volume method[M]. Beijing: National Defence Industry Press, (2005). (in Chinese).

[7] Yakhot V, Orszag S A. Renormalization group analysis of turbulence: I. Basic Theory[J]. Journal of Scientific Computing (1986), 1(1): 1-51.

DOI: 10.1007/bf01061452

[8] HAO Ji-guang, JIANG Yi, HAN Shu-yong, et al. A new dynamic mesh update method and its applications[J]. Journal of Ballistics, (2007), 19(2): 88-92. (in Chinese).

[9] Manninen M, Taivassalo V, Kallio S. On the mixture model for multiphase flow[J]. VTT publications 288, technical research centre of finland, (1996).

[10] Ma Yanli, Jiang Yi, Wang Weichen, Liu Bowei, Yan Feng. Research on the Wet-type Concentric Canister Launcher[J]. MISSILES AND SPACE VEHICLES, (2011).
