Research and Design of Novel Fractal Reader Antenna

Abstract:

This paper researches how the various iterations affect the characteristics of Minkowski fractal microstrip patch antenna. A 2-itration Minkowski fractal reader antenna is designed. In order to increase antenna bandwidth, the structure of a novel modified antenna is presented to operate at 2.45GHz with the return loss of -35.15dB and bandwidth of 180MHz, the maximum gain of which is 7.83dB. Besides, with its size of 30mm ×30mm, this antenna area is decreased by 43.75% and the width is decreased by 25% compared to normal square patch antenna. The simulation results show that it has a good size-reduction feature that can well meet the requirement for handheld RFID reader under certain size and characteristics.

• Periodical: Applied Mechanics and Materials (Volume 43)
• Pages: 101-104
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.43.101
• Online since: December 2010
• Authors: Zu Jue Chen, Zhi Hui Zhong, Shu Yan
• Keywords: Fractal Antenna, Microstrip Antenna, Radio Frequency Identification (RFID), Size-Reduction

References

[1] Ukkonen L, Sydanheimo L, Kivikoski: IEEE Application & Practice, Vol. 1 (No. 1) (2007), pp.24-31.

[2] Benoit. B Mandelbrot W.H. Freeman and Company, (1983).

[3] Carles Puente Baliarda, Jordi RomeU. IEEE Transactions on Antennas and Propagation, , Vol. 48(No. 11) (2000), pp.1773-1781.

DOI: 10.1109/8.900236

[4] Mohammed Z, Azad, Mohammod Ali. IEEE Transactions on Antennas and Propagation, 57(6) (2009), pp.1854-1858.

[5] K.J. Vinoy, A. Pal. IET Microwaves, Antennas & Propagation , Vol. 4(No. 2) (2010), pp.219-224.

[6] Qi dongxu. Science Press(1994).

[7] R. B. Waterhouse. Kluwer Academic Publishers(2003).

[8] M. Comisso. IET Microwaves, Antennas & Propagation, , Vol. 3(No. 3), (2009) pp.456-464.
