Distortion Correction of a Quick Response Code Image

Abstract:

Distortion typically occurs when images are captured from the surface of a cylindrical object. This problem is obvious in Quick Response (QR) code images, which necessitate distortion correction for subsequent information reading. Based on a detailed analysis of this distortion, we divided it into linear distortion along the generatrix direction and curl distortion perpendicular to the generatrix direction, and proposed a unified method to correct the distortion of both components. Experimental results are given to demonstrate the feasibility and applicability of the method.

• Periodical: Applied Mechanics and Materials (Volume 431)
• Pages: 312-317
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.431.312
• Online since: October 2013
• Authors: Xue Min Cheng*, Qun Hao, Chao Zhang, Jian She Ma
• Keywords: Distortion Correction, Mathematical Models, QR Code Image

References

[1] H. Liu: Journal Of Electronic Measurement And Instrument, 20(1), (2006), pp.32-35.

[2] J. Wei, S. Dai, P. Mu: Computer and Information Technology, 18, no. 6, 2010, pp.32-35.

[3] H. Cao, X. Ding, C. Liu: in ICDAR '03 Proceedings of the Seventh International Conference on Document Analysis and Recognition, (2003), p.71.

[4] Doncescu, A. Bouju, and V. Quillet: in Proc. Workshop Document Image Analysis, (1997), p.5–9.

[5] L. Lei, W. He, W. Zhang: in IEEE 2010 International Conference on Artificial Intelligence and Computational Intelligence, (2010).

[6] M. S. Brown, Y. Tsoi: IEEE Transaction on Image Processing, 15(6), (2006), pp.1544-1554.
