A Lyapunov-Based Control for a Single-Phase Shunt Hybrid Active Filter

Abstract:

In this paper, we analyze the control effect of the Lyapunov control strategy on the single-phase shunt hybrid active power filter based on the averaged state space model. The control law is derived by constructing an appropriate Lyapunov control function, and the switching signals is obtained through the pulse width modulation (PWM). The simulation results show that the Lyapunov-based control for a single-phase shunt hybrid active filter is of stability feature, and has good harmonic compensation performance. It presents better harmonic elimination compared to the the traditional PI and LQR controller.

• Periodical: Applied Mechanics and Materials (Volume 432)
• Pages: 464-471
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.432.464
• Online since: September 2013
• Authors: Hao Cheng, Chun Wen Li
• Keywords: Harmonics, Harmonics Compensation, Lyapunov, Single-Phase Shunt Hybrid Active Power Filter, Stability, State Space

References

[1] JIANG Qirong, XIE Xiaorong, CHEN Jianye, Power system shunt compensation-structure, theory, control and application[M]. China Machine Press, (2004).

[2] JIANG Qirong, ZHAO Dongyuan, CHEN Jianye, Active Power Filter system- structure, theory, control and application[M], China Science Press, (2005).

[3] Xiao Xiangning, Xu Yonghao, Research On Hybird Active Filter[J]. China, Power System Technology, 1997, 21(2): 48-52.

[4] F. Z. Peng, H. Akagi, and A. Nabae, A new approach to harmonic compensation in power-systems a combined system of shunt passive and series active-filters[J], IEEE Trans. Ind. Appl., vol. 26, pp.983-990, Nov. /Dec. (1990).

DOI: 10.1109/28.62380

[5] S. Srianthumrong and H. Akagi, A medium-voltage transformerless ac/dc power conversion system consisting of a diode rectifier and a shunt hybrid filter[J], IEEE Trans. Ind. Appl., vol. 39, pp.874-882, May/Jun. (2003).

DOI: 10.1109/tia.2003.811787

[6] HE Na, XU Dianguo, WU Jian, A Novel Design Method and Compound Control Strategy for Shunt Hybrid Power Filter[J], Automation Of Electric Power Systems vol. 31, pp.45-49, (2007).

DOI: 10.1109/ias.2005.1518516

[7] SalemRahmani, AbdelhamidHamadi, A Lyapunov-Function-Based Controlfora Three-Phase Shunt Hybrid Active Filter[J], IEEE Trans. vol. 59, No. 3, March (2012).

[8] WEI Yandi, ZHANG Yong, Control strategy for three-phase APF based on Lyapunov function[J], Electric Power Automation Equipment, Vol. 32 No. 1 (2012).

[9] HOU Shiying, ZENG Jianxing, SUN Tao, APF control strategy based on Lyapunov stability analysis[J], Electric Power Automation Equipment, 30(10), (2010).

[10] HasanKomurcugil, OsmanKukrer, Lyapunov-Based Control for Three-Phase PWMAC/DC Voltage-Source Converters[J], IEEE Trans. Vol. 13, No. 5, (1998).

[11] HUA C C，LI C H，LEE C S. Control analysis of an active powerfilter using Lyapunov candidate［J］. IET Power Electron，2009，2(4)：325-334.

DOI: 10.1049/iet-pel.2008.0235

[12] Komurcugil H，Kukrer O．A new control strategy forsingle-phase shunt active power filters using a Lyapunovfunction［J］．IEEE Trans on Industrial Electronics，2006，53(1)：305-312.

DOI: 10.1109/tie.2005.862218

[13] J. Miret, L. G. de Vicuna, M. Castilla, J. Matas, and J. M. Guerrero, Design of an analog quasi-steady-state nonlinear current-mode controller for single-phase active power filter[J], IEEE Trans. Ind. Electron., vol. 56, pp.4872-4881, Dec. (2009).

DOI: 10.1109/tie.2009.2026385

[14] D. A. Torrey and A. M. A. M. Alzamel, Single-phase active power filters for multiple nonlinear loads[J], IEEE Trans. Power Electron., vol. 10, pp.263-272, May (1995).

DOI: 10.1109/63.387990

[15] LEDWICH G, A GHOSH. A unified power quality conditioner (UPQC) for simultaneous voltage and current compensation[J]. Electric Power Systems Research, 2001, 59(1): 55-63.

DOI: 10.1016/s0378-7796(01)00141-9
