Finite Element Modeling and Analysis for a Certain Urban Bus Frame

Abstract:

Using CATIA set up a 3d model of urban bus frame in this paper, And ANSYS13.0 is used to establish the body frame finite element model of the certain urban bus body frame, Based on this model, the static characteristics under various conditions were analyzed, and the features of stress and strain distribution are gotten. Through the analysis of calculation results, we can conclude that this body frame around the column to the rear windscreen beam junction strength in insufficient, need to increase cross-sectional area of the left column; The floor behind driver seats strength is not enough, need to add two beams to strengthen the support. And the calculation result shows that the rest of the frame has a certain extent optimization space, and can provide the basis for the next step of lightweight.

• Periodical: Applied Mechanics and Materials (Volumes 433-435)
• Pages: 2239-2245
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.433-435.2239
• Online since: October 2013
• Authors: Ya Hui Li*, Wei Dong Luo, Rui Zhou
• Keywords: Body Frame, Light Weight, Modal Characteristics, Static Strength

References

[1] Feng Guo sheng. Finite element analysis of body structure of passenger car [J]. Journal of mechanical engineering, 1999, 35 (1) : 92-95.

[2] Gao Yu hua, Li Hua xiang, zhang Dai sheng. Finite element modeling and analysis of Half-integral body frame [J]. Journal of He Fei university of technology, 2007, 30 (4) : 494-497.

[3] Xu Zhi han, zhang Dai sheng. The modeling and optimization of bus body frame [J]. Journal of He Fei university of technology, 2009, 32 (9) : 108-110.

[4] Tang Shao hua, Liu Shi hao. The finite element analysis and optimization design of Passenger car body structure based on ANSYS [J]. Journal of digital design and digital manufacturing, 2007 (10).

[5] Guan Yi qun. The summary of finite element modeling method of passenger car [J]. Vehicle technology and research, 2006 (5).

[6] Huang Jun jie. The analysis of stiffness and strength of bus frame under the limited combined condition [J]. Journal of design and research, 2010 (5).

[7] Tan Ji jin, Zhang Dai sheng. The finite element analysis of the bus structure [M]. Beijing: tsinghua university press.

[8] Gu Ye shui. Finite element analysis and research of bus body frame structure. A master's degree thesis of He Fei university of technology. 2005, 5.
