Strength Analysis for Frame of Pavement Accelerated Loading Experimental Facility

Abstract:

Frame is an important bearing part of Pavement Accelerated Loading Experimental Facility. Static strength analysis of frame was made under four conditions by finite element analysis software ABAQUS. The four conditions are bending, twisting, emergency braking and urgent turning in full load. The frame strength and stiffness were analyzed and the stress distribution and displacement were got. According to the conclusion, the structure improvement suggestions are put forward such as increasing the beam thickness, adding cross beams between the side beams in the dangerous section. These suggestions can improve the design quality and enhance the facility safety.

• Periodical: Applied Mechanics and Materials (Volumes 433-435)
• Pages: 2286-2289
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.433-435.2286
• Online since: October 2013
• Authors: Qian Jia, Hui Jun Wang, Xing Yu Guo
• Keywords: Finite Element Analysis (FEA), Frame, Pavement Accelerated Loading Experimental Facility, Static Analysis

References

[1] Zhen Li, Lei Liu. The Chinese Version of the UGNX6 Application and Tutorial Examples. Beijing: Beijing Institute of Technology Press, (2009. 8) in Chinese.

[2] Xiushan Bai. Finite Element Analysis for Semi-trailer Frame Structure He Fei: He Fei University of Technology Master's Degree Thesis, (2004. 8) in Chinese.

[3] Lin Cheng, Sizhong Chen, Zhicheng Wu. The finite element analysis of heavy semi-trailer frame. The vehicle and power technology, fourth (2004) in Chinese.

[4] David V. Hutton . Fundamentals of Finite Element Analysis . McGraw-Hill Education(Asia) Companies , (2004. 3.

[5] Hongxin Zhang. Finite element theory and application of ANSYS. Machinery industry press, 2007. 1) in Chinese.

[6] Chuanwen Yu. Finite element simulation and optimization of structure of heavy truck frame . Changchun: jilin university master's degree thesis, (2005) in Chinese.
