Uncertainty Estimation of Probe Calibrations Using a Power Flux Density System of (18~26.5) GHz

Abstract:

A method for the uncertainty estimation of probe calibrations using the power flux density (PFD) system of (18~26.5) GHz recently developed at the National Institute of Metrology, China is presented. A measurement model is developed first, and then the sources of uncertainty and the corresponding evaluation procedures are explained. The method is used to estimate the uncertainty of the calibration factor of a FP7050 probe at 18 GHz obtained by the PFD system. The good agreement between the calibration results from two PFD systems validates the method.

• Periodical: Applied Mechanics and Materials (Volumes 433-435)
• Pages: 882-886
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.433-435.882
• Online since: October 2013
• Authors: Jin Yuan Li, Ming Xie
• Keywords: Power Flux Density (PFD), Probe Calibration, Standard Field Method, Uncertainty

References

[1] IEEE Std 1309-2005, IEEE Standard for Calibration of Electromagnetic Field Sensors and Probes, Excluding Antennas, From 9 kHz to 40 GHz.

DOI: 10.1109/ieeestd.2005.98650

[2] ISO (BIPM/IEC/IFCC/ISO/IUPAC/IUPAP/OIML), Guide to the Expression of Uncertainty in Measurement, (1995).

[3] M. Xie, D. Meng, P. Huang, X. Gao, and F. Wu: Acta Metrologica Sinica Vol. 30(4) (2009), p.354. (in Chinese).

[4] Y. Ni: Practical Evaluation of Measurement Uncertainty (China Metrology Publishing House, Beijing 2008). (in Chinese).
