A Novel Small-Size Coupled-Line Wilkinson Power Divider for Dual-Band Applications

Abstract:

A novel coupled-line circuit configuration is proposed to design small-size dual-band Wilkinson power dividers. This proposed power divider consists of three sections of coupled lines and two isolation resistors. The analytical design theory is given and the electrical parameters analysis is provided. Six numerical examples are presented to demonstrate the flexible dual-band applications. To avoid a negative isolation resistor, a practical power divider operating at 1GHz and 2.2GHz with two positive-value resistors is designed. The calculated and full-wave simulated results verify our proposed idea. Keywords: Coupled-line, dual-band, power divider.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 1066-1072
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.1066
• Online since: October 2013
• Authors: Wei Min Wang*, Yuan An Liu
• Keywords: Coupled-Line, Dual-Band, Power Divider
