Analysis of Fluid Film Lubrication of an MHD Journal Bearing Subjected to an Axially Applied External Magnetic Field

Abstract:

This work simulates the steady-state flow field in a magnetohydrodynamic journal bearing. A uniform magnetic field is applied in the axial direction across the bearing. Current results indicate that a crescent-shape secondary flow will develop at E = 0.8. The velocity profiles at the location of the minimum and maximum film thickness are almost independent of the strength of the external magnetic field unless the eccentricity ratio is relatively small and magnetic field is strong. There exists an eccentric dependent threshold Ha beyond which the shear stress on the journal increases with Ha while that on the bearing decreases.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 136-139
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.136
• Online since: October 2013
• Authors: Chin Lung Chang, Yu Min Li, Hsing Hui Huang, Jik Chang Leong*
• Keywords: Axially Applied External Magnetic Field, Computational Study, Journal Bearing, Mhd Flow

References

[1] W.F. Huges, The Magnetohydrodynamic Inclined Slider Bearing with a Transverse Magnetic Field, Wear 6 (1963) 315-324.

DOI: 10.1016/0043-1648(63)90164-9

[2] D.C. Kuzma, The Magnetohydrodynamic Journal Bearing, J. Fluids Engin. 85 (1963) 424-427.

[3] D.C. Kuzma, The Finite Magnetohydrodynamic Journal Bearing, J. Fluids Engin. 86 (1964) 445-448.

[4] J.B. Shukla, Hydromagnetic Theory for Squeeze Films, J. Basic Engin. 87 (1965) 142-144.

DOI: 10.1115/1.3650490

[5] E.R. Maki, D.C. Kuzma, R.L. Donnelly, Magnetohydrodynamic Lubrication Flow between Parallel Plates, J. Fluid Mech 26 (1966) 537-543.

DOI: 10.1017/s002211206600137x

[6] M.I. Anwar, C.M. Rodkiewicz, Nonuniform Magnetic Field Effects in MHD Slider Bearings, ASME J. Lubr. Technol. 94 (1972) 101-105.

DOI: 10.1115/1.3451626

[7] V.M. Soundalgekar, Effects of an External Circuit on a MHD Slider Bearing, Wear 21 (1972) 17-25.

DOI: 10.1016/0043-1648(72)90246-3

[8] N.C. Das, A Study of Optimum Load Capacity of Slider Bearings Lubricated with Power Law Fuids, Tribol. Int. 32 (1999) 435-441.

DOI: 10.1016/s0301-679x(99)00072-9

[9] J.R. Lin, R.F. Lu, Dynamic Characteristics for Magneto-hydrodynamic Wide Slider Bearings with an Exponential Film Profile, J. Mar. Sci. Tech. 18 (2010) 268-276.

[10] S. Kamiyama, Magnetohydrodynamic Journal Bearing, J. Lubr. Technol. 91 (1969) 380-386.

[11] M. Malik, D.V. Singh, Analysis of Finite Magnetohydrodynamic Journal Bearings, Wear 64 (1980) 273-280.

DOI: 10.1016/0043-1648(80)90133-7

[12] E.A. Hamza, The Magnetohydrodynamic Effects on a Fuid Film Squeezed between two Rotating Surfaces, J. Phys. D 24 (1991) 547-554.

DOI: 10.1088/0022-3727/24/4/005

[13] V.M. Soundalgekar, A.S. Amrute, Effects of External Circuit on MHD Squeeze Film between Conducting Plates, Wear 19 (1972) 117-122.

DOI: 10.1016/0043-1648(72)90298-0

[14] J.R. Lin, Magneto-hydrodynamic Squeeze Film Characteristics between a Sphere and a Plane Surface, J. Mar. Sci. Technol. 11 (2003) 174-178.

[15] R.F. Lu, R.D. Chien, J.R. Lin, Effects of Fluid Inertia in Magneto-hydrodynamic Annular Squeeze Films, Trib. Int. 39 (2006) 221-226.

DOI: 10.1016/j.triboint.2004.05.010

[16] J. -S. Kuo, J.C. Leong, Analysis of a Conducting Fluid in a Thin Annulus with Rotating Insulated Walls under Radial Magnetic Effect, Appl. Math. Model. 37 (2013) 3021-3035.

DOI: 10.1016/j.apm.2012.07.011
