Bionic and Reconfigurable Force Amplifiers Based on the Length and Angle Effect of Bars

Abstract:

Observation of the present force amplification mechanism suggests geometrically simple bars have length effect and angle effect, both contributing to the amplification of force. Those bars are prevalent in animal bone structures. A set of design methodology and principles of reconfigurable force amplification mechanism is presented based on bionics. Following a few basic rules, engineers could use bars to construct innovative structures with various functions to meet practical requirements. Some example cases are displayed along with related equations. The effects of lever and toggle mechanism in series are compared to that of ordinary systems. The former displays remarkable advantages.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 164-170
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.164
• Online since: October 2013
• Authors: Chuan Yang Wang*, Yun Xia Dou, Kang Min Zhong
• Keywords: Angle Effect, Force Amplification Mechanism, Length Effect, Lever, Reconfigurable Mechanism, Toggle Mechanism

References

[1] Zhong Kangmin, Dou Yunxia, Su Dongning, Wang Hongyan. CNC Press Based on the High-Speed Linear Servo Motor and Two-stage Symmetrical Orthogonal Toggle Force Amplifying Mechanism. Proceedings of ASME2009 International Mechanical Engineering Congress and Exposition.

DOI: 10.1115/imece2009-11019

[2] Si Guangju, Zhong Kangmin. Green clamping devices based on two-step orthogonal toggle force amplifier driven by pneumatic muscle. 2009 IEEE International Conference on Mechatronics and Automation, ICMA 2009, pp.1596-1600, (2009).

DOI: 10.1109/icma.2009.5246034

[3] Chen Zhi-song, Zhong Kang-min Analysis and application of hinge-rod and lever series connected combination mechanism. Journal of Machine Design(CHINA), 2010(1)：57-58, 63.

[4] Wang Jin-e, Dou Yun-xia, Zhong Kang-min. The Performance Comparison of Four types of Pneumatic Presses Based on Force Amplifier Toggle. Chinese Hydraulics & Pneumatics, 2009(9)：54-55, 53.

[5] Wang Jin-e, Dou Yun-xia, Zhong Kang-min. Reconfigurable pneumatic press machine based on force amplifier toggle and cylinder with rod-less piston. Journal of Engineering Design(CHINA), 2009, 16(4)：242-246.

[6] Dou Yun-xia, Zhong Kang-min. A Hydraulic-Mechanical Driving Press with Bi-bar Toggle-lever Force Amplifier in Series Manufacturing Technology & Machine Tool(CHINA), 2009(8)：54-55, 53.

[7] Dou Yun-xia, Zhong Kang-min. A Double-acting Hydraulic-mechanical Driving Press with Bi-bar Toggle Force Amplifier Based on Rolling Higher Pair. Machine Tool & Hydraulics(CHINA), 2009(6): 102-103, 73.

DOI: 10.1115/imece2009-12501

[8] Li Xin, Zhong Kang-min, Su Dong-ning, Reflex typed 3 staged serial permanent force increasing lever mechanism. Journal of Machine Design(CHINA), 2009(3): 61-62.

[9] Zhong Kangmin, Guo Peiquan. Orthogonal reinforcement mechanism. and hydraulic drive. In: Proceedings of tenth world congress on the theory of machines and mechanisms(Vol5). Oulu, Finland: Oulu University Press, 1999, 2037～(2042).

[10] Zhong Kangmin, Guo Peiquan, Hu Bingchen. Centrifugal clutch with orthogonal force amplifier. Chinese Journal of Mechanical Engineering(CHINA), 2000, 36(4): 38-40, 44.

DOI: 10.3901/jme.2000.04.038
