Modeling and Simulation on Transformer Computer Protection in Wind Farm

Abstract:

This paper studies a single machine infinite bus system with two-winding transformer and access 110KV power system after improveing voltage. We established a system model of transformer based on MATLAB/Simulink, and established the computer protection data acquisition system model in wind farm, studied second harmonic ratio brake differential protection. Setted calculation combined with actual differential protection for a given parameter transformer, and use the simulink to simulate test of short-circuit. By the simulation study, we investigated the performance of transformer differential protection.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 173-176
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.173
• Online since: October 2013
• Authors: De Tian, Hai Hui Song*
• Keywords: Computer Protection, Fourier Algorithm, Simulation, Transformer, Wind Farm

References

[1] OU M X. Analysis and Realization of Transformer Computer Protection's Double Configuration[J]. Qinghai Electric Power, 2003, 3.

[2] XU J Z. A micro_computer system on a transformer differential protection based on fuzzy set and scalar product breaking theory [J]. RELAY, 2001, 9.

[3] QIN J Y, RUAN J J. Lightning over-voltage analysis of 110 kV transformer neutral point[J]. High Voltage Engineering, v33, n1, 2007, 1.

[4] HUANG F C, WEI Y H. Transient model of three phase multi-legged transformer based on duality theory[J]. Proceedings of the Chinese Society of Electrical Engineering, v27, n3, 2007, 1.
