Route Length, Curve Radius and Layout of Evacuated Tube Maglev Space Launch System

Abstract:

Current space launch is expensive and low-efficient because the invalid load----rocket and fuel in it occupies over 80% of the total launch weight. A solution to reduce the space launch cost and increase the launch efficiency is to construct the evacuated tube, pump air out from the tube and have the maglev vehicle loaded with the spacecraft run in it; the spacecraft fly out the tube when the maglev is accelerated to ultra-speed, e.g. 5km/s even 8km/s in the tube. By this way, the first class of the rocket could be saved, so that the launch cost would be low and lead the large scale space exploitation to become reality in the soon future. As for the tube construction, the route layout should be concerned on at first. Because of the engineering restriction, the height at the tube end wouldnt be very high, and the embedding depth wouldnt be very deep, practically about 8km. However, the tube length will be 700km at least, a completely straight tube or a completely curve tube (on a single circle) would lead a too small launch angle. Thus both of them are not feasible. Reasonable tube routes in vertical section will include two or more than two segments, for example, a straight tube segment and a curve tube segment, or two or more than two curve segments in different radius or different curve direction.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 93-97
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.93
• Online since: October 2013
• Authors: Yao Ping Zhang
• Keywords: Curve Radius, Evacuated Tube Maglev, Launch Angle, Layout, Route Length, Space Launch

References

[1] Y. P. Zhang, Evacuated tube transportation and vacuum industry development, Vacuum, Vol. 43 (2006) 56-59 (in Chinese).

[2] Y. P. Zhang, Y. Y. Li, Role and position of ETT in the future comprehensive transportation system, 2007 ICTEC, The American Society of Civil Engineers, ASCE(2007) 2796-2803.

[3] Y. P. Zhang, J. Y. Yu, M. X. Shen, et al, Affecting factors and numerical value calculation relating to vacuumizing time in evacuated tube transportation, IFOST 2011, Harbin, China(2011)246-249.

DOI: 10.1109/ifost.2011.6021014

[4] Y. P. Zhang, Evacuated tube transportation routes: go through overhead, on ground, shallow underground or deeply underground? CTEE 2012, Nanjing (2012) 287-292.

DOI: 10.2495/ctee120421

[5] Information on http: /www. et3. com.

[6] P. James, M. George, P. John, Is NTP the key to exploring space? AEROSPACE AMERICA, ISSN 0740-722X, (2004).

[7] P. James, M. George, R. John, Maglev Launch: Ultra Low Cost Ultra/High Volume to Space for Cargo and Humans, SPESIF-2010 - Space, Propulsion, and Energy Sciences International Forum February 23, 26, (2010).

DOI: 10.1063/1.3326240

[8] Information on http: /www. startram. com.
