Computational Fluid Dynamics Simulation of the Exterior Flow Field around an Aerodynamic Reference Model

Abstract:

The exterior flow field around a Ford notchback automobile aerodynamic reference model was investigated using a commercial Computational Fluid Dynamics (CFD) code, Ansys Fluent. Two computational domains were set up in order to represent different model mounting conditions. According to the comparisons, good simulation accuracy could be obtained using the steady state k-ω SST model with small size near wall mesh (y⁺<5) simulations. The comparatively large prediction errors of the surface pressure coefficient of the model centerline happened in two positions. One is the roof trailing edge, where the flow separation begins. The other is the saddle point on the deck lid centerline, where the reverse flow emerges. These differences between the CFD and experiment were possibly due to the unstable wake. This wake instability would be the reason of the differences between the Ford notchback model transverse vortices and the typical notchback car wake structures.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 85-88
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.85
• Online since: October 2013
• Authors: De Jiu Wu, Xing Jun Hu, Bo Yang*
• Keywords: Automotive Aerodynamics, Exterior Flow Structures, Near Wall Computational Mesh, Notchback Automobile, Numerical Simulation Accuracy

References

[1] Mayer, W. and Wickern, G. The new Audi A6/A7 family - aerodynamic development of different body types on one platform. SAE Technical Paper, 2011(2011-01-0175).

DOI: 10.4271/2011-01-0175

[2] Carr, G.W. Potential for Aerodynamic Drag Reduction in Car Design. International Journal of Vehicle Design, 1983, Special Publication SP3, 44-56.

[3] Jenkins, L.N. An Experimental Investigation of the Flow Over the Rear End of a Notchback Automobile Configuration. SAE Paper, 2000, 2000-01-0489.

DOI: 10.4271/2000-01-0489

[4] Williams, J., Quinlan, W.J., Hackett, J.E., Thompson, S.A., marinaccio, T. and Robertson, A. A Calibration Study of CFD for Automotive Shapes and CD. SAE Paper, 1994, 940323.

DOI: 10.4271/940323

[5] Hajiloo, A., Williams, J., Hackett, J.E. and Thompson, S.A. Limitied Mesh Refinement Study of the Aerodynamic Flow Field Around a Car-Like Shape: Computational Versus Experimental Fluid Dynamics. SAE Paper, 1996, 960677.

DOI: 10.4271/960677

[6] Carr, G.W. Influence of Rear Body Shape on the Aerodynamic Characteristics of Saloon Cars. (MIRA Report, 1974).
