Shear Resistance of Pre-Cracking Reinforced Concrete T-Beam Strengthening with CFRP Sheets

Abstract:

Eleven pre-cracking reinforced concrete T-beams were strengthened with U-stirrups and longitudinal sheets of CFRP, the main parameters were the width, layer and space of U-stirrups of CFRP. The tests for shear resistance of the beams were carried out to measure the diagonal crack development and crack width, mid-span deflection, CFRP strain and ultimate resistance. Compared with the reference beam without strengthening, the diagonal cracks were effectively restrained and the shear resistances of the beams were also strengthened by the U-stirrups of CFRP. However, the shear resistance increment of the beams were not in direct proportion with the amount of CFRP sheet characterized by the width, layer and space of U-stirrups, as the strengthening effect is obviously influenced by the bond quality and the anchorage reliability of the U-stirrups. When strengthened with one layer, the shear resistance of the beam was enhanced largely by the wider sheet. When strengthened with two layers, the enhancement of shear resistance was weakened with the increasing width of sheets.

• Periodical: Applied Mechanics and Materials (Volumes 438-439)
• Pages: 472-476
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.438-439.472
• Online since: October 2013
• Authors: Shun Bo Zhao, Jun Feng Li, Feng Jun Shi, Zhong Hua Du
• Keywords: CFRP Sheet, Pre-Cracking, Reinforced Concrete T-Beam, Shear Resistance, Strengthening

References

[1] Teng J.: FRP Strengthening Concrete Structures (China Building Industry Press, Beijing, 2005).

[2] Carlo Pellegrino and Claudio Modena: ACI Structural Journal Vol. 103 No. 5 (2006), pp.720-728.

[3] Giorgio Monti and M. A. Liotta: Construction and Building Materials No. 21 (2007), pp.799-809.

[4] Triantafillou T. C.: ACI Structural Journal, Vol. 95 No. 2 (1998), pp.107-115.

[5] Islam M. R., M. A. Mansur and M. Maalj: Cement and Concrete Composites No. 27 (2005), pp.413-419.

[6] Khalifa A. And A. Nanni: Cement and Concrete Composites No. 22, pp.165-174.

[7] Bousselham A. and Omar Chaallal: ACI Structural Journal Vol. 103 No. 3 (2006), pp.339-347.

[8] Christophe Deniaud and J. J. Roger Cheng: Journal of Composite for Construction Vol. 7 No. 4 (2003), pp.302-310.

[9] Pan L., S. Chen, S. Zhao and C. Li: Applied Mechanics and Materials Vols. 201-201 (2012), pp.483-486.

[10] Zhao W., X. Li and S. Zhao: Yellow River Vol. 34 No. 6 (2012), pp.136-138.

[11] GB50367-2006: Design Code for Strengthening Concrete Structure (China Building Industry Press, Beijing, 2006).
